ROBOT3T- 3C MACHINERY CO., LTD
6/4, 328 Cao Lo Street, Ward 4, District 8, Hochiminh City, Vietnam
Email: sales@robot3t.com
(+84) 97-490-8615
USER MANUAL THC3T-02 STEP/DIR Page 5 | 16
2
A
Area for control
A001 to A050
Device will change to auto mode when
the arc voltage from:
[Voltage Set - Area for control] to
[Voltage Set + Area for control]
3
S
Sensitive
S100 to S800
This parameter determines the value
respond of Z axis motion.
4
P
Arc-voltage
P000 to P300
Display the arc voltage value from
plasma cutter.
5
d
Delay time
d001 to d099
The delay time to send ARC_OK from
0.1 to 10s: THC will sent ARC_OK
signal after this delay, the main purpose
is Z axis not move down at the first time
of cutting.
6
v
Run speed
v001 to v099
Change speed of motor from 0 to 100%
of max speed. This parameter only affect
in STEP/DIR version.
7
SW1
ON or OFF
Change the direction of Z motor.
3 Signals summary of THC3T-02
3.1 Power supply
Table2. Parameters on LED display
