ROBOT3T- 3C MACHI
NERY CO., LTD
6/4, 328 Cao Lo Street, Ward 4, District 8, Hochiminh City, Vietnam
Email: sales@robot3t.com
(+84) 97-490-8615
USER MANUAL
THC3T-02 UP/
DOWN
Page
6
|
21
The main parameters o
f the master board:
Table1. Main para
meter
Parameter name
Acceptable
Supply voltage
+24V
DC
/2A ±10%
Maximum arc-voltage
660VDC
Maximum input voltag
e of 1:50 divider
6.6VDC
Maximum current of
output relays
150mA/100VDC
Weight
300g
External Dimensions (
L * W * H)
95x110x45[mm]
1.4
Divider
board
SW MODE
DIVIDER
SW 1
SW 2
De
scription
100:1
ON
ON
Voltage divide ratio 1:
100
50:1
OFF
ON
Voltage divide ratio 1:
50
ON
OFF
EXT
-
50:1
OFF
OFF
Voltage input of 1:50
divider EXT(extension
)
Fig4. Divider board
5
7
Table of Contents
Default Chapter
2
Table of Contents
2
1 Device Information
3
Introduction
3
Specifications
4
Mainboard
5
Divider Board
6
2 Signals Summary of THC3T-02
7
Power Supply
7
Arc-Voltage
7
Potentiometer
10
Output ACR_OK, THC_UP & THC_DOWN (OPTO)
11
3 Setup Parameters
12
4 THC3T-02 Operations
13
Principle Operating
13
Fast Connect
14
5 Fault Processing
17
6 Example for MACH3 Configuration
18
7 Warranty Period and Coverage
20
Warranty Period
20
Warranty Coverage
20
Notes on Safety
20
