FBL2360 Brushless DC Motor Controller Datasheet 17
Electrical Specifications
Scripting
TABLE 11.
Parameter Measure Point Min Typ Max Units
Scripting Flash Memory Internal 32K Bytes
Max Basic Language programs Internal 2000 3000 Lines
Integer Variables Internal 4096 Words (1)
Boolean Variables Internal 8192 Symbols
Execution Speed Internal 50000 100000 Lines/s
Note 1: 32-bit words
Thermal Specifications
TABLE 12.
Parameter Measure Point Min Typ Max Units
Case Temperature Case -40 85 (1)
o
C
Thermal Protection range Case 80 90 (2)
o
C
Power Dissipation Case 70 Watts
Thermal resistance Power MOSFETs to case 0.6
o
C/W
Humidity Case 95 %
Ambient temperature Ambient 55
o
C
Pollution Degree -
Fast fuse to install (3) FBL2360 (4) 40 2 x 40 Amps
FBL2360S (4) 2 x 40 Amps
Overload motor protection - Check note 5
Note 1: Thermal protection will protect the controller power
Note 2: Max allowed power out starts lowering at minimum of range, down to 0 at max of range
Note 3: There are two power terminal tabs. Fuse should be installed in both of them for safety.
Note 4: In dual channel controller, for operating only one channel install 40A fuse and for operating both
channels 2 x 40A fuse should be installed. Power source must be capable to blow the fuse instantly in
case of short circuit
Note 5: Current limiting mechanism available through firmware. External overload motor protection can
be used if required (provided by user)
