FBL2360 Brushless DC Motor Controller Datasheet 3
Power Wires Identifications and Connection
Important Safety Disclaimer
Dangerous uncontrolled motor runaway condition can occur for a number of
reasons, including, but not limited to: command or feedback wiring failure,
configuration error, faulty firmware, errors in user script or user program, or
controller hardware failure.
The user must assume that such failures can occur and must make his/her system
safe in all conditions. Roboteq will not be liable in case of damage or injury as a
result of product misuse or failure.
Power Wires Identifications and Connection
Power connections are made by means of faston tabs located at the back of the controller.
I/O ConnectorHall Sensors
Connector
USB
Connector
LEDsSTO
Jumper
FIGURE 1. FBL2360 front view
Pwr
CtrlVMOTGND U1V1W1U2V2W2
FIGURE 2. FBL2360 rear view
