Robotex AVATAR III - Robot Range and Signal Strength Troubleshooting; PTZ Camera Not Working

 


23

Avatar®IIIUserManualRevD12/2015

5:Ifared“X”isdisplayedoverthesignalstrengthindicatoronthecontroller
screen,therobotradiomaybehavingaproblem.Firsttryturningtherobotoff
andonbyremovingandreinstallingthebattery.Ifthisdoesnotsolvetheproblem
tryremovingtherobotradio.Toremovetherobotradio,firstbesurethata
batteryisnotinstalledintherobot.Removetherobotradiobylooseningthetwo
largeflatheadscrewsoneithersideofthehandleatthebackoftherobot.Once
thescrewsareloose,pullthehandleandtheentirerobotradiowiththeantenna
willcomeoutoftherobot.Besurethattheelectricalconnectorsontherobot
radioandthecorrespondingconnectorsontherobotareclean.Reinstalltherobot
radiobyhand,beingsurethattherobotradioisfullyseated,thentightenthetwo
flatheadscrewsfirmlyandtesttoseeiftheproblemisresolved.Iftheproblem
persistscallourCustomerSupportline.

6:Ifayellowtriangleisdisplayedoverthesignalstrengthindicatoronthe
controllerscreen,thecontrollerradiomaybehavingaproblem.Firsttryturning
thecontrolleronandoffseveraltimes.Ifthisdoesnotfixtheproblem,try
removingandthenreinstallingthecontrollerradio.First,besurethatthe
controllerisoff.Toremovethecontrollerradio,loosenthetwoflatheadscrews
onthebacksideofthecontroller.Oncethescrewsarecompletelyloosegently
pull/prythecontrollerradiooffofthecontroller.Besurethatheelectrical
connectorsonthecontrollerradioandthecorrespondingconnectorsonthe
controllerareclean.Reinstallthecontrollerradiobyseatingtheradiobyhand
thentightenthetwoflatheadscrewsfirmlyandtesttoseeiftheproblemis
resolved.IftheproblempersistscallourCustomerSupportline.


B. ThePanTiltZoomcameradoesnotwork.

1:TryusingthePTZcameraresetfeatureonthecontroller.

2:RemovethebatterythenremoveandreinstallthePTZcamera.Toremove
the
PTZcamera,loosenthe4flatheadscrewsateachcornerofthePTZcamera.When
all4screwsareloose,pulluponthecameraandremoveitfromtherobot.Besure
thattheelectricalconnectoronthePTZcameraandthecorrespondingconnector
ontherobotare
clean.ReinstallthePTZcamerabymakingsurethatitisfully
seatedbyhand,thentightendownthe4mountingscrewsandtesttoseeifthe
problemisresolved.IftheproblempersistscallourCustomerSupportline.






