INSTALLATION
INSTALLATION
REMOTE CONTROL INSTALLATION
8. Insert the remote control into the holder.
7. Attach the remote control holder to the wall
using the screws provided.
3.Determine a location for the holder where is visible and
reachable from the toilet and make sure the infrared
signal is well communicated between remote control
and main unit.
4.The right figure is the guide line for the remote
controller position.
5.Before fix the bracket to the wall make sure the
eception is correct and the MULTICLIN work
properly.
6.If the remote controller can’t activate the MULTICLIN,
move the remote controller within the indicated
area on the wall to find a best IR reception location.
1. Load two AA (R6) size batteries (included) into the Remote Control
2.Tighten battery cover with screwdriver
-
+
-
+
30cm
30cm
80~110cm
30cm
30
(mm)
6
