RocketFish RF-RBUSB - Using as a Wireless Receiver

17
RF-RBUSB
Using as a wireless receiver
The wireless sender/receiver can be connected to an amplifier or
amplified speaker to receive music from other Rocketboost wireless
senders.
An example configuration is shown below.
Connect your powered speaker or amplifier to the LINE Out jack on the
rear of the wireless sender/receiver using the 3.5 mm audio cable. If
necessary, you can also use the 3.5 mm to RCA adapter, if your audio
device uses RCA-type line in connectors.
RF-RBUSB (Rocketboost
Wireless sender)
RF-RBUSB (Rocketboost
Wireless receiver)
or
Included 3.5 mm cable
To audio
input jack
Included 3.5 mm cable and 3.5 mm to RCA adapter
