14
Need help? Call 1-800-620-2790 (U.S. or Canada)
Step 6 - Option 2: Installing on a solid concrete or concrete
block wall
CAUTION: To prevent property damage or personal injury, never drill into
mortar between blocks. Mount the arm assembly directly onto the
concrete surface.
1 Align the wall plate template (E) at the height you determined in the previous
step and make sure that it is level. Tape the wall plate template to the wall, then
use a pencil to mark the lag bolt hole locations (2). Remove the wall plate
template.
2 Drill pilot holes to a depth of 3 in. (75 mm) using a 3/8 in. (10 mm) diameter
masonry drill bit.
3 Insert the concrete wall anchors* into the pilot holes and use a hammer to make
sure the anchors are flush with the concrete surface.
4 Align the arm assembly (A) with the anchors, insert the lag bolts (T) through the
lag washers (S) and the holes in the arm assembly (A), then tighten the bolts only
until they are firm against the arm assembly (A).
CAUTION: Avoid potential injuries or property damage!
DO NOT over-tighten the lag bolts (T).
*Not included. Call Customer Service to have the Fischer UX10 x 60 concrete anchor
kit (Kit# CMK1) shipped directly to you.
