RocketFish RF-TVMFM02V2 User Manual

15
Need help? Call 1-800-620-2790 (U.S. or Canada)
TV WALL MOUNT RF-TVMFM02V2/RF-TVMFM02V2-C
You’ll need
1
2
3
4
75 mm
3 in.
Wall
Home
position
Full
extension
Note: TV shifts 6.99 in. (177.5 mm)
laterally from the home position to full
extension.
9.72 in. (246.9 mm)
6.99 in.
(177.5 mm)
Note: Minimum solid concrete thickness:
8 in (203 mm). Minimum concrete block
size: 8 x 8 x 16 in. (203 x 203 x 406 mm).
See Note*
* Note: Not
included. Call
Customer Service
to have the
Fischer UX10 x 60
concrete anchor
kit (Kit# CMK1)
shipped directly
to you.
Lag bolt T (2)
Pencil
Drill
1/2" socket wrench
Level
Hammer
Template (E)
3/8" masonry drill bit
Arm assembly (A)
Tape
S (2)
