7
Need help? Call 1-800-620-2790 (U.S. and Canada)
TV WALL MOUNT RF-TVMLPT03V3
STEP 3 - Option 1: Attaching the mounting hardware to
TVs with a flat back
1 Align the holes you noted on the TV brackets (B and C) with the screw holes on
the back of your TV. The brackets are marked “R” for the right bracket and “L” for
the left bracket. Make sure that the brackets are level.
2 Place the washers (G or H) over the holes in the TV brackets that align with the
screw holes on the back of your TV, then insert the screws (E, K, M, N, or O)
through the washers.
3 Tighten the screws until they are snug against the TV bracket. Do not over
tighten.
You’ll need
G (4)
H (4)
E (4) K (4) M (4)
Phillips screwdriver
oror
or
Screws
or
N (4)
Washers
Level
(B and C) TV
Brackets
or
O (4)
To Next Page
