17
Need help? Call 800-620-2790
RF-TVMP40 TV Wall Mount
STEP 9 - Installing the cable wrap and cable ties
1 Connect the cable to your TV, then secure the cable to the underside of the arm assembly (A) with two cable
ties (P-L).
2 Install the cable wrap (P-D) on the cables to provide a neater appearance.
You’ll need
P-D
P-L
P-D Cable wrap (1)
P-L Cable ties (2)
RF-TVMP40_13-0238_MAN_V1_ENG.fm Page 17 Monday, April 15, 2013 1:26 PM
