Follow these steps to connect the replaceable battery.
1. Insert the replaceable battery wire connector into the battery connector.
2. Secure the battery connector wires along the wire guide as shown below.
ESC OK
Wire Guide
Battery Connector Wires
Replaceable
Battery
Replaceable Battery Pocket
Battery Wire Connector
Battery Connector
