Rockwell Automation 1763-L16BBB - Hazardous Location Considerations

8
Publication 1763-IN001C-EN-P - June 2015
Hazardous Location Considerations
This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D or non-hazardous
locations only. The following WARNING statement applies to use in hazardous locations.
Catalog
Number
Description
Input
Power
Digital
Inputs
Analog
Inputs
Digital
Outputs
Comm.
Ports
1763-L16AWA 120/240V ac (10) 120V ac (2) voltage input
0...10V dc
(6) relay
All individually
isolated
(1) RS-232/485
combo
(isolated)
(1) Ethernet
1763-L16BWA 120/240V ac (6) 24V dc
(4) high-speed
24V dc
(1)
(1)
The 4 high-speed inputs (inputs 0 through 3) can be used for pulse latching or higher speed counting. Refer to Input
Specifications on page 25 and the MicroLogix 1100 Instruction Set Reference Manual, publication 1763-RM001, for more
information.
(2) voltage input
0 ...10V dc
(6) relay
All individually
isolated
(1) RS-232/485
combo
(isolated)
(1) Ethernet
1763-L16BBB 24V dc (6) 24V dc
(4) high-speed
24V dc
(1)
(2) voltage input
0...10V dc
(2) relay (isolated)
(2) 24V dc FET
(2) high-speed
24V dc FET
(1) RS-232/485
combo
(isolated)
(1) Ethernet
1763-L16DWD 12/24V dc (6) 12/24V dc
(4) high-speed
12/24V dc
(1)
(2) voltage input
0...10V dc
(6) relay
All individually
isolated
(1) RS-232/485
combo
(isolated)
(1) Ethernet
