34 Publication 1769-UM020A-EN-P - December 2009

Chapter 3 Module Data, Status, and Channel Configuration

Channel Configuration

Each channel is independently configured via a group of eight

consecutive words in the Configuration Data file. The first two words

of the group consist of bit fields, the settings of which determine how

the output channel operates. See the tables below and the

descriptions that follow for valid configuration settings and their

meanings. The default bit status of the configuration file is all zeros.

Bit Definitions for Channel Configuration Words

Define To choose Make these bit settings

15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00

Program to Fault

Enable (PFE)

(1)

Program Data 1

Fault Data

Program Mode (PM)

(1)

User-defined 1

Hold Last State 0

Fault Mode (FM)

(1)

User-defined 1

Hold Last State 0

Enable Ramping (ER)

(1)

Enable 1

Disable 0

Latch Clamp Status

(LC)

Enable 1

Disable 0

Enable Low Clamp

Alarm Interrupt (ELI)

(2)

Enable 1

Disable 0

Enable High Clamp

Alarm Interrupt (EHI)

(2)

Enable 1

Disable 0

Enable Channel (EC) Enable 1

Disable 0

(1) Alternate output states are not supported by all controllers. Refer to your controller’s user manual to determine whether alternate output states and this module function

are supported.

(2) Module interrupts are not supported by all controllers. Refer to your controller’s user manual to determine whether module interrupts are supported.

Bit Definitions for Type/Range and Data Format Configuration Words

Define To choose Make these bit settings
