Publication 1769-UM020A-EN-P - December 2009 61
Appendix
C
Configuration Using the RSLogix 5000 Generic
Profile for CompactLogix Controllers
Introduction
If the Add-on Profile for the 1769-OF4 module is not yet available,
follow this procedure to configure your module by using a generic
profile.
Add the Module to Your
Project
1. Start RSLogix 5000 software.
2. From the File menu, choose New to open an existing project or
start a new project.
3. If this is a new project select a CompactLogix controller, type a
name for the controller, and click OK.
Topic Page
Add the Module to Your Project 61
Configure Each I/O Module 64
