Rockwell Automation Allen-Bradley FLEX 1794-AENT User Manual

Rockwell Automation Publication 1794-IN082F-EN-P - October 2022 5
FLEX I/O EtherNet/IP Adapters Installation Instructions
Overview
The FLEX™ I/O EtherNet/IP™ adapter with an RJ45 port facilitates data transfer across an EtherNet/IP network between FLEX I/O modules and a controller.
EtherNet/IP Adapter
Install Your Adapter
Component Identification
1 EtherNet/IP adapter
2 Flexbus connector
3 24V common connections
4 24V DC connections
5 IP address switches
6 Adapter DIN rail locking tab
7 Network cable RJ45 connector (underside)
8 MAC ID label
9 Status indicators
1
9
8
7
6
5
4
3
2
1794-AENT/B
A
B
C

Rockwell Automation Allen-Bradley FLEX 1794-AENT Specifications

General

Brand	Rockwell Automation
Model	Allen-Bradley FLEX 1794-AENT
Category	Adapter
Language	English
