42 Rockwell Automation Publication 442G-UM002B-EN-P - August 2021
Appendix A Specifications
Environmental
Physical Characteristics
Attribute Value
Ambient temperature
at UB = DC 24V
-20…+55 °C (-4…+131 °F)
Storage temperature -20…+65 °C (-4…+149 °F)
Enclosure rating IP54
Operating humidity 5…80% relative
Vibration/shock
IEC 60068-2-27 30 g (1.06 oz), 11 ms/IEC 60068-2-6
10…55 Hz
Attribute Value
Weight
• Lock/bus assembly on mounting plate: 3.6 kg (7.9 lb)
• Handle assembly on mounting plate: 1.2 kg (2.6 lb)
• Escape release: 500 g (17.6 oz)
Materials
• Glass fiber reinforced plastic
• Nickel-plated die-cast zinc
• Anodized aluminum handle
•Stainless steel
• Powder-coated sheet steel
