English-20 PowerFlex 400P Adjustable Frequency AC Drive Quick Start
T056
T061
[Relay Out1 Level]
[Relay Out2 Level]
0.0/9999 0.1 0.0
T058 [Relay 1 On Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T059 [Relay 1 Off Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T063 [Relay 2 On Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T064 [Relay 2 Off Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T065 [Opto Out Sel] 0/24 0 = “Ready/Fault”
1 = “At Frequency”
2 = “MotorRunning”
3 = “Hand Active”
4 = “Motor Overld”
5 = “Ramp Reg”
6 = “Above Freq”
7 = “Above Cur”
8 = “Above DCVolt”
9 = “Above Anlg 2”
10 = “Above PF Anlg”
11 = “Anlg In Loss”
12 = “ParamControl”
13 = “Retries Exst”
14 = “NonRec Fault”
15 = “Reverse”
16 = “Logic In 1”
17 = “Logic In 2”
18 = “Logic 1 & 2”
19 = “Logic 1 or 2”
20 = “StpLogic Out”
21 = “Timer Out”
22 = “Counter Out”
24 = “Fault”
1
T066 [Opto Out Level] 0.0/9999 0.1 0.0
T068 [Opto Out Logic] 0/1 1 0
T069 [Analog In 1 Sel] 0/6 1 2
T070
T074
[Analog In 1 Lo]
[Analog In 2 Lo]
0.0/100.0% 0.1% 0.0%
T071
T075
[Analog In 1 Hi]
[Analog in 2 Hi]
0.0/100.0% 0.1% 100.0%
T072
T076
[Analog In 1 Loss]
[Analog In 2 Loss]
0/6 0 = “Disabled”
1 = “Fault (F29)”
2 = “Stop”
3 = “Zero Ref”
4 = “Min Freq Ref”
5 = “Max Freq Ref”
6 = “Preset Freq0”
7 = “Hold Last”
0
No. Parameter Min/Max Display/Options Default
T055 and T060 Setting T056 and T061 Min/Max
6 0/320 Hz
7 0/180%
8 0/815 Volts
9 0/100%
10 1/180 degs
12 0/1
17 1/9999 counts
21 0.1/9999 seconds
T065 Setting T066 Min/Max
6 0/320 Hz
7 0/180%
8 0/815 Volts
9 0/100%
10 1/180 degs
12 0/1
T068 Option Opto Out Logic
0 NO (Normally Open)
1 NC (Normally Closed)
T069 Option Setting Input Range DIP Switch AI1 Setting
0 Current Mode 0-20 mA 20 mA
1 Current Mode 4-20 mA 20 mA
2 Voltage Mode - Unipolar 0-10V 10V
4 Current Mode (Square Root) 0-20 mA 20 mA
5 Current Mode (Square Root) 4-20 mA 20 mA
6 Voltage Mode - Unipolar (Square Root) 0-10V 10V
22P-QS001C-EN-P.fm Page 20 Thursday, March 30, 2017 5:55 PM
