PowerFlex 400P Adjustable Frequency AC Drive Quick Start English-21
T073 [Analog In 2 Sel] 0/7 1 2
T077 [Sleep-Wake Sel] 0/4 0 = “Disabled”
1 = “Analog In 1”
2 = “Analog In 2”
3 = “Command Freq”
4 = “Ind Slp Wake”
0
T078 [Sleep Level] 0.0/100.0% 0.1% 10.0%
T079 [Sleep Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T080 [Wake Level] 0.0/100.0% 0.1% 15.0%
T081 [Wake Time] 0.0/600.0 Secs 0.1 Secs 0.0 Secs
T082
T085
[Analog Out1 Sel]
[Analog Out2 Sel]
0/29 1 0
1
T083
T086
[Analog Out1 High]
[Analog Out2 High]
0/800% 1% 100%
T084
T087
[Anlg Out1 Setpt]
[Anlg Out2 Setpt]
0.0/100.0% 0.1% 0.0%
T088 [Anlg Loss Delay] 0.0/20.0 Secs 0.1 Secs 0.0 Secs
T089 [Analog In Filter] 0/14 1 0
T090 [Sleep Sel] 0/7 0 = “AI1 > SlpLvl”
1 = “AI1 < SlpLvl”
2 = “AI2 > SlpLvl”
3 = “AI2 < SlpLvl”
4 = “OFrq>SlpLvl”
5 = “OFrq<SlpLvl”
6 = “CFrq>SlpLvl”
7 = “CFrq<SlpLvl”
0
No. Parameter Min/Max Display/Options Default
T073 Option Setting Input Range DIP Switch AI2 Setting
0 Current Mode 0-20 mA 20 mA
1 Current Mode 4-20 mA 20 mA
2 Voltage Mode - Unipolar 0-10V 10V
3 Voltage Mode - Bipolar -10 to +10V 10V
4 Current Mode (Square Root) 0-20 mA 20 mA
5 Current Mode (Square Root) 4-20 mA 20 mA
6 Voltage Mode - Unipolar (Square Root) 0-10V 10V
7 Voltage Mode - Bipolar (Square Root) -10 to +10V 10V
Setting
Output
Range Min. Output Value Max. Output Value Filter
DIP
Switch
AO1
Related
Parameter
0 OutFreq 0-10 0-10V 0V = 0 Hz [Maximum Frequency] None 10V b001
1 OutCurr 0-10 0-10V 0V = 0 Amps 200% Drive Rated FLA Filter A 10V b003
2 OutTorq 0-10 0-10V 0V = 0 Amps 200% Drive Rated FLA Filter A 10V b013
3 OutVolt 0-10 0-10V 0V = 0 Volts 120% Drive Rated Output V None 10V b004
4 OutPowr 0-10 0-10V 0V = 0 kW 200% Drive Rated Power Filter A 10V b010
5 Setpnt 0-10 0-10V 0V = 0.0% 100.0% Setpoint Setting None 10V T084
6 TstData 0-10 0-10V 0V = 0000 65535 (Hex FFFF) None 10V A196
7 OutFreq 0-20 0-20 mA 0 mA = 0 Hz [Maximum Frequency] None 20 mA b001
8 OutCurr 0-20 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b003
9 OutTorq 0-20 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b013
10 OutVolt 0-20 0-20 mA 0 mA = 0 Volts 120% Drive Rated Output V None 20 mA b004
11 OutPowr 0-20 0-20 mA 0 mA = 0 kW 200% Drive Rated Power Filter A 20 mA b010
12 Setpnt 0-20 0-20 mA 0 mA = 0.0% 100.0% Setpoint Setting None 20 mA T084
13 TstData 0-20 0-20 mA 0 mA = 0000 65535 (Hex FFFF) None 20 mA A196
14 OutFreq 4-20 4-20 mA 4 mA = 0 Hz [Maximum Frequency] None 20 mA b001
15 OutCurr 4-20 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b003
16 OutTorq 4-20 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA Filter A 20 mA b013
17 OutVolt 4-20 4-20 mA 4 mA = 0 Volts 120% Drive Rated Output V None 20 mA b004
18 OutPowr 4-20 4-20 mA 4 mA = 0 kW 200% Drive Rated Power Filter A 20 mA b010
19 Setpnt 4-20 4-20 mA 4 mA = 0.0% 100.0% Setpoint Setting None 20 mA T084
20 TstData 4-20 4-20 mA 4 mA = 0000 65535 (Hex FFFF) None 20 mA A196
21 MinFreq 0-10 0-10V 0 V = [Minimum Freq] [Maximum Freq] None 10 V P034
22 MinFreq 0-20 0-20 mA 0 mA = [Minimum Freq] [Maximum Freq] None 20 mA P034
23 MinFreq 4-20 4-20 mA 4 mA = [Minimum Freq] [Maximum Freq] None 20 mA P034
24 AnlgIn1 0-10 0-10V 0V = 0.0% 100.0% Setting Filter A 10V d305
25 AnlgIn1 0-20 0-20 mA 0 mA = 0.0% 100.0% Setting Filter A 20 mA d305
26 AnlgIn1 4-20 4-20 mA 4 mA = 0.0% 100.0% Setting Filter A 20 mA d305
27 AnlgIn2 0-10 0-10V 0V = 0.0% 100.0% Setting Filter A 10V d306
28 AnlgIn2 0-20 0-20 mA 0 mA = 0.0% 100.0% Setting Filter A 20 mA d306
29 AnlgIn2 4-20 4-20 mA 4 mA = 0.0% 100.0% Setting Filter A 20 mA d306
T083 Setting T082 Setting T082 Max. Output Value
50% 1 “OutCurr 0-10” 5V for 200% Drive Rated Output Current
90% 11 “OutPowr 0-20” 18 mA for 200% Drive Rated Power
22P-QS001C-EN-P.fm Page 21 Thursday, March 30, 2017 5:55 PM
