PowerFlex 400P Adjustable Frequency AC Drive Quick Start English-25
R241
R244
R247
[Aux 1 Start Freq]
[Aux 2 Start Freq]
[Aux 3 Start Freq]
0.0/320.0 Hz 0.1 Hz 50.0 Hz
R242
R245
R248
[Aux 1 Stop Freq]
[Aux 2 Stop Freq]
[Aux 3 Stop Freq]
0.0/320.0 Hz 0.1 Hz 25.0 Hz
R243
R246
R249
[Aux 1 Ref Add]
[Aux 2 Ref Add]
[Aux 3 Ref Add]
0.0/100.0% 0.1% 0.0%
R250 [Aux Start Delay] 0.0/999.9 Secs 0.1 Secs 5.0 Secs
R251 [Aux Stop Delay] 0.0/999.9 Secs 0.1 Secs 3.0 Secs
R252 [Aux Prog Delay] 0.00/60.00 Secs 0.01 Secs 0.50 Secs
R253 [Aux AutoSwap Tme] 0.0/999.9 Hrs 0.1 Hrs 0.0 Hr
R254 [Aux AutoSwap Lvl] 0.0/100.0% 0.1% 50.0%
No. Parameter Min/Max Display/Options Default
Advanced Display Group Parameters
No. Parameter Min/Max Display/Options Default
d301 [Control Source] 0/99 Digit 0: Start Command
0 = Keypad
1 = Terminal Block
2 = Communications
Digit 1: Speed Command
0 = Local Keypad Pot
1 = A142
2 = Analog Input 1
3 = Analog Input 2
4 = A143-146
5 = Communications
Read Only
d302 [Contrl In Status] 0/1
(1 = Condition True)
Read Only
d303 [Comm Status] 0/1
(1 = Condition True)
Digit 0: Received Good Message Packet
Digit 1: Transmitting Message
Digit 2: DSI Peripheral Connected
Digit 3: Received Bad Message Packet
Read Only
d304 [PID Setpnt Displ] 0.0/100.0% 0.1% 0.0%
d305
d306
[Analog In 1]
[Analog In 2]
0.0/120.0% 0.1% 0.0%
d307
d308
d309
[Fault 1 Code]
[Fault 2 Code]
[Fault 3 Code]
0/122 1 Read Only
d310
d312
d314
[Fault 1 Time-hr]
[Fault 2 Time-hr]
[Fault 3 Time-hr]
0/32767 Hrs 1 Hrs Read Only
d311
d313
d315
[Fault 1 Time-min]
[Fault 2 Time-min]
[Fault 3 Time-min]
0.0/60.0 Min 0.1 Min Read Only
d316 [Elapsed Time-hr] 0/32767 1 Hr Read Only
d317 [Elapsed Time-min] 0.0/60.0 Min 0.1 Min Read Only
d318 [Output Powr Fctr] 0.0/180.0 deg 0.1 deg Read Only
d319 [Testpoint Data] 0/FFFF 1 Hex Read Only
d320 [Control SW Ver] 1.00/99.99 0.01 Read Only
d321 [Drive Type] Used by Rockwell Automation field service personnel.
d322 [Output Speed] 0.0/100.0% 0.1% Read Only
d323 [Output RPM] 0/24000 RPM 1 RPM Read Only
d324 [Fault Frequency] 0.00/320.00 Hz 0.01 Hz Read Only
Display Digit (Right to Left) I/O Terminal Control Input
0 02 Start/FWD In
1 03 Dir/REV In
2 01 Stop Input
3 05 Digital In 1
4 06 Digital In 2
5 07 Digital In 3
6 08 Digital In 4
22P-QS001C-EN-P.fm Page 25 Thursday, March 30, 2017 5:55 PM
