PowerFlex 400P Adjustable Frequency AC Drive Quick Start English-5
Refer to the PowerFlex 400P User Manual, publication 22P-UM001
for details on how to comply with the Low Voltage (LV) and
Electromagnetic Compatibility (EMC) Directives.
EMC Line Filters
CE Conformity
480V 50/60 Hz 3-Phase 480V 50/60 Hz 3-Phase
kW HP Catalog Number kW HP Catalog Number
2.2 3.0 22-RF018-CS 45 60 22-RFD100
4.0 5.0 22-RF018-CS 55 75 22-RFD150
5.5 7.5 22-RF018-CS 75 100 22-RFD180
7.5 10 22-RF018-CS 90 125 22-RFD208
11 15 22-RF026-CS 110 150 22-RFD208
15 20 22-RFD036 132 200 22-RFD323
18.5 25 22-RFD050 160 250 22-RFD480
22 30 22-RFD050 200 300 22-RFD480
30 40 22-RFD070 250 350 22-RFD480
37 50 22-RFD100
Drive Ratings
Catalog
Number
Output Ratings Input Ratings Branch Circuit Protection
Power
Dissipation
kW (HP)
(1)
Amps
(2)
Voltage
Range kVA Amps Fuses
(3)
140M Motor
Protectors
(4)
Contactors
IP20 Open
Watts
380 - 480V AC – 3-Phase
Input, 0 - 460V 3-Phase Output
22P-D6P0N103 2.2 (3.0) 6 340-528 6.3 7.5 10 140M-D8E-C10 100-C09 105
22P-D010N103 4.0 (5.0) 10.5 340-528 10.9 13 20 140M-D8E-C16 100-C16 171
22P-D012N103 5.5 (7.5) 12 340-528 11.9 14.2 20 140M-D8E-C16 100-C23 200
22P-D017N103 7.5 (10) 17 340-528 15.3 18.4 25 140M-D8E-C20 100-C23 267
22P-D022N103 11 (15) 22 340-528 19.2 23 30 140M-F8E-C32 100-C30 329
22P-D030N103 15 (20) 30 340-528 25.8 31 40 140M-F8E-C32 100-C37 435
22P-D038A103 18.5 (25) 38 340-528 33.3 40 50 140M-F8E-C45 100-C60 606
22P-D045A103 22 (30) 45.5 340-528 39.1 47 60 140-CMN-6300 100-C60 738
22P-D060A103 30 (40) 60 340-528 53.3 64 80 140-CMN-9000 100-C85 664
22P-D072A103 37 (50) 72 340-528 60.7 73 100 140-CMN-9000 100-C85 1019
22P-D088A103 45 (60) 88 340-528 74.9 90 125 – 100-D110 1245
22P-D105A103 55 (75) 105 340-528 89 107 150 – 100-D140 1487
22P-D142A103 75 (100) 142 340-528 124.8 150 200 – 100-D180 2043
22P-D170A103 90 (125) 170 340-528 142 170 250 – 100-D250 2617
22P-D208A103 110 (150) 208 340-528 167 200 250 – 100-D250 3601
22P-D260A103 132 (200) 260 340-528 196 235 300 – 100-D300 3711
22P-D310A103 160 (250) 310 340-528 242 290 400 – 100-D420 4208
22P-D370A103 200 (300) 370 340-528 304 365 500 – 100-D420 4916
22P-D460A103 250 (350) 460 340-528 387 465 600 – 100-D630 6167
(1)
Ratings based on Normal Duty application only.
(2)
Current ratings based on ambient temperature of 45°C.
(3)
Recommended Fuse Type: UL Class J, CC, T or Type BS88; 600V (550V) or equivalent.
(4)
Refer to the Bulletin 140M Motor Protectors Selection Guide, publication 140M-SG001… to
determine the frame and breaking capacity required for your application.
22P-QS001C-EN-P.fm Page 5 Thursday, March 30, 2017 5:55 PM
