English-6 PowerFlex 400P Adjustable Frequency AC Drive Quick Start
Specifications, Fuses and Circuit Breakers
Category Specification
Agency
Certification
Marked for all applicable European Directives
EMC Directive (2014/30/EU)
EN 61800-3
Low Voltage Directive (2014/35/EU)
EN 61800-5-1
Protection Bus Overvoltage Trip: 380-460V AC Input: 810V DC bus voltage (equivalent to 575V AC
incoming line)
Bus Undervoltage Trip: 380-480V AC Input: 390V DC bus voltage (equivalent to 275V AC
incoming line)
Power Ride-Thru: 100 milliseconds
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
Electronic Motor Overload
Protection:
I
2
t protection - 110% for 60 seconds (Provides Class 10
protection)
Overcurrent: 180% hardware limit, 220% instantaneous fault
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Electrical Efficiency: 97.5% at rated amps, nominal line voltage
Control
Output Frequency: 0-320 Hz (programmable)
Control
Inputs
Digital: Quantity: (3) Semi-programmable
(4) Programmable
Type
Source Mode (SRC):
Sink Mode (SNK):
18-24V = ON, 0-6V = OFF
0-6V = ON, 18-24V = OFF
Analog: Quantity: (1) Isolated, –10 to 10V or 4-20 mA
(1) Non-isolated, 0 to 10V or 4-20 mA
Specification
Resolution:
0 to 10V DC Analog:
4-20mA Analog:
External Pot:
10-bit
100k ohm input impedance
250 ohm input impedance
1-10k ohm, 2 Watt minimum
Control
Outputs
Relay: Quantity: (2) Programmable Form C
Specification
Resistive Rating:
Inductive Rating:
3.0A at 30V DC, 3.0A at 125V, 3.0A at 240V AC
0.5A at 30V DC, 0.5A at 125V, 0.5A at 240V AC
Optional
Relay
Card:
Quantity: (6) Optional Programmable Form A
(Not available for Frame C drives)
Specification
Resistive Rating:
Inductive Rating:
0.1A at 30V DC Class II circuits, 3.0A at 125V,
3.0A at 240V AC
0.1A at 30V DC Class II circuits, 3.0A at 125V
3.0A at 240V AC
Opto: Quantity: (1) Programmable
Specification: 30V DC, 50mA Non-inductive
Analog: Quantity: (2) Non-Isolated, 0-10V or 4-20mA
Specification
Resolution:
0 to 10V DC Analog:
4-20mA Analog:
10-bit
1k ohm minimum
525 ohm maximum
