Rockwell Automation Publication 750-RN034B-EN-P - November 2014 9
PowerFlex 753 Drives (revision 10.003)
4. Now that the correct communication device has been selected, you must
select which device is being updated. With the Select the PowerFlex…
dialog box displayed, follow these steps.
a. Expand the hardware view for the communication path you are using
(
in Figure 4).
b. Select the drive icon that represents the PowerFlex 753 drive you are
updating (
in Figure 4).
c. Click OK (
in Figure 4).
Figure 4 - Selecting the Correct Drive to Flash
5. In the Multiple Assemblies Found display box, select
“Port x-PowerFlex 753” from the list and click OK.
