8 Rockwell Automation Publication 750-RN034B-EN-P - November 2014
PowerFlex 753 Drives (revision 10.003)
Using ControlFLASH to Flash Update
1. With the Flash Kit installed (see Installing the Flash Kit on page 4), launch
ControlFLASH by selecting Start > (All) Programs > Flash
Programming Tools > ControlFLASH.
2. On the ControlFLASH Welcome dialog box, click Next >.
3. The Catalog Number dialog box appears. From the list, choose the
communication device you will use to update the PowerFlex 753 drive. In
the figure below, the embedded EtherNet device is selected.
Once the appropriate communication device is selected, click Next >.
