PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Appendix B
Accessories and Dimensions
Table B.A Catalog Number Description
Table B.B PowerFlex 40 Drives
Product Selection
22B - A 1P5 N 1 1 4
Drive Voltage Rating Rating Enclosure HIM Emission Class Type
Drive Ratings IP20, NEMA/UL Type Open
IP20 Flange
Mount
(1)
IP66, NEMA/UL
Type 4X
Input Voltage kW HP
Output
Current Catalog Number
Frame
Size Catalog Number Catalog Number
120V 50/60 Hz
1-Phase
No Filter
0.4 0.5 2.3A 22B-V2P3N104 B 22B-V2P3F104 22B-V2P3C104
0.75 1.0 5.0A 22B-V5P0N104 B 22B-V5P0F104 22B-V5P0C104
1.1 1.5 6.0A 22B-V6P0N104 B 22B-V6P0F104 22B-V6P0C104
240V 50/60 Hz
1-Phase
With Integral “S
Type” EMC
Filter
0.4 0.5 2.3A 22B-A2P3N114 B – –
0.75 1.0 5.0A 22B-A5P0N114 B – –
1.5 2.0 8.0A 22B-A8P0N114 B – –
2.2 3.0 12.0A 22B-A012N114 C – –
240V 50/60 Hz
1-Phase
No Filter
0.4 0.5 2.3A 22B-A2P3N104 B 22B-A2P3F104 22B-A2P3C104
0.75 1.0 5.0A 22B-A5P0N104 B 22B-A5P0F104 22B-A5P0C104
1.5 2.0 8.0A 22B-A8P0N104 B 22B-A8P0F104 22B-A8P0C104
2.2 3.0 12.0A 22B-A012N104 C 22B-A012F104 –
240V 50/60 Hz
3-Phase
No Filter
0.4 0.5 2.3A 22B-B2P3N104 B 22B-B2P3F104 22B-B2P3C104
0.75 1.0 5.0A 22B-B5P0N104 B 22B-B5P0F104 22B-B5P0C104
1.5 2.0 8.0A 22B-B8P0N104 B 22B-B8P0F104 22B-B8P0C104
2.2 3.0 12.0A 22B-B012N104 B 22B-B012F104 22B-B012C104
3.7 5.0 17.5A 22B-B017N104 B 22B-B017F104 22B-B017C104
5.5 7.5 24.0A 22B-B024N104 C 22B-B024F104 –
7.5 10.0 33.0A 22B-B033N104 C 22B-B033F104 –
480V 50/60 Hz
3-Phase
No Filter
0.4 0.5 1.4A 22B-D1P4N104 B 22B-D1P4F104 22B-D1P4C104
0.75 1.0 2.3A 22B-D2P3N104 B 22B-D2P3F104 22B-D2P3C104
1.5 2.0 4.0A 22B-D4P0N104 B 22B-D4P0F104 22B-D4P0C104
2.2 3.0 6.0A 22B-D6P0N104 B 22B-D6P0F104 22B-D6P0C104
4.0 5.0 10.5A 22B-D010N104 B 22B-D010F104 22B-D010C104
5.5 7.5 12.0A 22B-D012N104 C 22B-D012F104 –
7.5 10.0 17.0A 22B-D017N104 C 22B-D017F104 –
11.0 15.0 24.0A 22B-D024N104 C 22B-D024F104
(2)
–
600V 50/60 Hz
3-Phase
No Filter
0.75 1.0 1.7A 22B-E1P7N104 B 22B-E1P7F104 22B-E1P7C104
1.5 2.0 3.0A 22B-E3P0N104 B 22B-E3P0F104 22B-E3P0C104
2.2 3.0 4.2A 22B-E4P2N104 B 22B-E4P2F104 22B-E4P2C104
4.0 5.0 6.6A 22B-E6P6N104 B 22B-E6P6F104 22B-E6P6C104
5.5 7.5 9.9A 22B-E9P9N104 C 22B-E9P9F104 –
7.5 10.0 12.0A 22B-E012N104 C 22B-E012F104 –
11.0 15.0 19.0A 22B-E019N104 C 22B-E019F104 –
(1)
Meets IP40/54/65 (NEMA 1/12/4/4X) when installed in an enclosure of like rating.
(2)
Requires use of external DC Bus Inductor or AC Line Reactor. See Table B.E for details.
22B-UM001.book Page 1 Tuesday, May 30, 2017 5:22 PM
