D-2 RJ45 DSI Splitter Cable
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
DSI Cable Accessories
RJ45 Splitter Cable – Catalog Number: AK-U0-RJ45-SC1
RJ45 Two-Position Terminal Block Adapter –
Catalog Number: AK-U0-RJ45-TB2P
RJ45 Adapter with Integrated Termination Resistor –
Catalog Number: AK-U0-RJ45-TR1
Slave Port
Master Port
PIN
8
PIN 1
M
S
TB2
(PIN 5)
TB1
(PIN 4)
PIN 8
PIN 1
PIN 8
PIN 1
