Rockwell Automation Publication 6300P-UM001B-EN-P - March 2021 7
Preface
This manual is a user guide for VersaView® 6300P panel PCs. It provides
procedures to the following:
Install the computer.
Make computer connections.
Operate the computer.
Troubleshoot the computer.
A general knowledge of automation technology is needed to understand and
follow the instructions in this publication.
Knowledge of personal computers and Microsoft Windows® operating
systems are required to understand and follow the instructions in this
publication.
Catalog Numbers
This publication is applicable to these 6300P panel PCs. For your catalog
number, see the product label on the side of your computer.
Summary of Changes
This publication contains the following new or updated information. This list
includes only substantive updates and is not intended to reflect all changes.
Additional Resources
These documents contain additional information about related products from
Rockwell Automation.
You can view or download publications at rok.auto/literature
.
Cat. No. Identifier Bezel Type Bezel Material
Touchscreen
Type
6300P-***BAPS…
Standard
Aluminum Resistive6300P-***FAPS…
6300P-***AAPS…
Low profile6300P-***ACPM… Aluminum glass True Flat
PCAP
6300P-***ECPM…
Topic Page
Removed HD and SVGA, and added WXGA as an available display resolution in the bullet point. 9
Updated the operating temperature range of the computers and added the corresponding footnote. 14
Expanded the ambient air humidity parameters. 14
Removed Intel Celeron from the table in Power Consumption subsection. 18
Removed the footnote and UL reference for the SELV power supply requirement. 19
Replaced artwork with photograph in Table 1. 20
Added row that green signifies watchdog is working to item 3 in Table 2. 22
Resource Description
VersaView 6300P Panel PC Installation Instructions,
publication 6300P-IN001
Provides basic installation guidelines and instructions for
VersaView 6300P panel PCs.
VersaView 6300 Industrial Computer and Monitor
Specifications Technical Data, publication IC-TD003
Provides technical specifications about the VersaView
6300M industrial panel monitors.
Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1
Provides general guidelines for installing a Rockwell
Automation industrial system.
Product Certifications website,
rok.auto/certifications
Provides declarations of conformity, certificates, and other
certification details.
