Chapter 2 Installation
PanelView Plus 600 Dimensions
The depth dimensions are shown for:
• base-configured unit (display module and logic module).
• base-configured unit with communication module.
268 (10.47)
167
98
68
71
154 (6.08)
185
152
98
71
154 (6.08)
600 Keypad or Keypad/Touch Terminal
600 Touch Terminal
68
