Publication 2711P-UM001I-EN-P - December 2008 185
Terminal Connections Chapter 7
Minimum Requirements
The software and firmware must be installed on the development
computer and the PanelView Plus terminal to configure and
communicate with an Allen-Bradley controller on a ControlNet
network.
ControlNet Unscheduled Communications
ControlNet Scheduled Communications
Software/Firmware PanelView Plus 700 to 1500 PanelView Plus 400 or 600
FactoryTalk View Studio Version 3.10 or later Version 4.0 or later
FactoryTalk View Machine Edition Runtime Version 3.10 or later Version 4.0 or later
ControlNet Module Firmware 2711P-RN15S, Series A, Rev A
(firmware version 2.07 or later)
(1)
2711P-RN15C, Series B, Rev A
or later
(1)
This applies to terminals that are ordered as pre-configured units with the ControlNet module.
Requirements PanelView Plus 700 to 1500 PanelView Plus 400 or 600
FactoryTalk View Studio Version 3.20 or later Version 4.0 or later
FactoryTalk View Machine Edition Runtime Version 3.20.04 or later Version 4.0 or later
RSNetWorx for ControlNet Version 5.11 or later Version 6.0 or later
RSLogix 5000 Version 13.0 or later Version 15.0 or later
ControlNet Module Firmware 2711P-RN15S, Series A, Rev C
(firmware version 3.08 or later)
(1)
2711P-RN15C, Series B, Rev A
or later
(1)
This applies to terminals that are ordered as preconfigured units with the ControlNet module.
WARNING
The ControlNet Communications Module, cat. no.
2711P-RN15S, will not run with FactoryTalk View ME firmware
version 3.20.04 or earlier. All ControlNet Modules with version
3.07 firmware must be upgraded to version 3.08 or later;
otherwise, outputs may turn on an indeterminate state.
