Rockwell Automation PanelView Plus Series

Publication 2711P-UM001I-EN-P - December 2008 229
Appendix A
Specifications
Electrical
Environmental
Attribute Value
400 and 600
Input voltage, DC
Power consumption, DC
700 to 1500
Input voltage, DC
Power consumption, DC
24V DC nom (18…30V DC)
25 W max (1.0 A at 24V DC)
24V DC nom (18…32V DC)
70 W max (2.9 A at 24V DC),
39 W typical (1.6A @ 24V DC)
400 and 600
Input voltage, AC
Line frequency
Power consumption, AC
700 to 1500
Input voltage, AC
Line frequency
Power consumption, AC
Remote power 700 to 1500 (2711P-RSAC)
Input voltage, AC
Line frequency
Power consumption, AC
85…264V AC
47…63 Hz
60V A max
85…264V AC
47…63 Hz
160V A max, 65 VA typical
85…264V AC
47…63 Hz
120V A max
PCI slot max available power
Supply, DC
Supply, AC
11 W
5 W
Attribute Value
Temperature, operating 0…55 °C (32…131 °F)
Temperature, non-operating -25…70 °C (-13…158 °F)
Heat dissipation
400 and 600
700 to 1500
85 BTU/hr
240 BTU/hr
Relative humidity 5…95% without condensation
Altitude, operating 2000 m (6561 ft)
Shock, operating 15 g at 11 ms
Shock, nonoperating 30 g at 11 ms
