Rockwell Automation PanelView Plus Series User Manual

Publication 2711P-UM001I-EN-P - December 2008 69
Configuration Mode Chapter 4
DHPlus Properties
Field Description Valid Values
Jumper ID Identifies the communication card if multiple
cards are installed on terminal.
0…3
Station Number The unique address of the terminal on the
DHPlus network.
0…77 (octal)
Baud Rate The communication rate of the DHPlus
network.
57,600 (default)
115,200
230,400
DH-485 Properties
Field Description Valid Values
Jumper ID Identifies the communication card if multiple
cards are installed on terminal.
0…3
Station Number The unique station number of the terminal on
the DH-485 network.
0…31 (decimal)
Baud Rate The communication rate of the DH-485
network.
9600
19,200
MaxStationNumber The maximum station number on the DH-485
network. The value must be greater than or
equal to the Station Number.
0…31 (decimal)
Remote I/O Properties
Field Description Valid Values
Jumper ID Identifies the communication card if multiple
cards are installed on terminal.
0…3
Baud Rate The communication rate of the remote I/O
network.
57,600 (default)
115,200
230,400
ControlNet Properties
Field Description Valid Values
Device ID Unique address of the PanelView Plus
terminal on the ControlNet network.
1…99
DeviceNet Properties
Field Description Valid Values
MacID Unique address of the terminal on the
DeviceNet network.
0…63
Baud Rate The communication rate at which the
DeviceNet driver communicates.
125 Kbps (default)
250 Kbps
500 Kbps
