SMC™ Flex Quick Start 15
Repair Parts
➀
One piece provided per part number.
➁ Three-phase power pole structure provided per part no.
➂ One-phase power pole provided per part no.
➃ Refer to Appendix D in the SMC Flex User Manual, for installation instructions.
Description SMC Rating
Part No.
➀
For units rated 200…600V AC
For units rated 690V
AC
100…240V AC 24V AC/DC 100…240V AC
Control Modules Standard All 41391-454-01-S1FX 41391-454-02-S2FX 41391-454-05-S1FZ
Pump All 41391-454-01-B1FX 41391-454-02-B2FX 41391-454-05-B1FZ
Braking 5…85 A 41391-454-01-D1AX 41391-454-02-D2AX 41391-454-05-D1AZ
108…251 A 41391-454-01-D1BX 41391-454-02-D2BX 41391-454-05-D1BZ
317…480 A 41391-454-01-D1CX 41391-454-02-D2CX 41391-454-05-D1CZ
625…780 A 41391-454-01-D1DX N/A 41391-454-05-D1DZ
970…1250 A 41391-454-01-D1EX N/A 41391-454-05-D1EZ
Description SMC Rating Series
Part No.
➀
Line Voltage
200…480V 200…600V 230…690V
Power Poles 5 A B 150-FPP5B ➁ 150-FPP5C ➁ N/A
25 A B 150-FPP25B ➁ 150-FPP25C ➁ N/A
43 A B 150-FPP43B ➁ 150-FPP43C ➁ N/A
60 A B 150-FPP60B ➁ 150-FPP60C ➁ N/A
85 A B 150-FPP85B ➁ 150-FPP85C ➁ N/A
108 A A 41391-800-01
➂ 41391-800-02 ➂ N/A
135 A A 41391-800-03
➂ 41391-800-04 ➂ N/A
108 A B 150-FPP108B ➁ 150-FPP108C ➁ 150-FPP108Z ➁
135 A B 150-FPP135B ➁ 150-FPP135C ➁ 150-FPP135Z ➁
201 A B
150-FPP201B 150-FPP201C 150-FPP201Z
➂
251 A B 150-FPP251B 150-FPP251C 150-FPP251Z
➂
317 A B 150-FPP317B 150-FPP317C 150-FPP317Z
➂
361 A B 150-FPP361B 150-FPP361C 150-FPP361Z
➂
480 A B 150-FPP480B 150-FPP480C 150-FPP480Z
➂
625 A B 150-FPP625B 150-FPP625C 150-FPP625Z
➂
780 A B 150-FPP780B 150-FPP780C 150-FPP780Z
➂
970 A B 150-FPP970B 150-FPP970C 150-FPP970Z ➂
1250 A B 150-FPP1250B 150-FPP1250C 150-FPP1250Z
➂
Heatsink Fans 5…85 A B 41391-801-03
108…135 A B 41391-801-03
201…251 A B 41391-801-01
317…480 A B 41391-801-02
110/120V AC
Control P
ower
625
…1250 A B 41391-801-04
230/240V AC
Control Power
625
…1250 A B 41391-801-05
Base Plate 201…251 A B 41391-803-01
317…480 A B 41391-803-02
By-Pass
Contactor ➃
110/120V AC
Control Power
625…780 A B 100-D180ED11
970…1250 A B 100-D420ED11
230/240V AC
Control Power
625
…780 A B 100-D180EA11
970…1250 A B 100-D420EA11
