SMC™ Flex Quick Start 7
Control Wiring
Refer to the product nameplate for additional details. Depending on the specific application, additional control
circuit transformer VA capacity may be required.
Controllers rated 5…480 A
Control power is connected to the product through terminals 11 and 12.
Controllers rated 625…1250 A
Control power is connected to the product through terminal block CP1, at terminals 1 and 4.
Conductor Range
0.75…2.5 mm
2
(18…14 AWG)
Torque 0.6 N•m (5 lb•in)
Maximum Number of Wires per Terminal 2
AC Control Voltage Input 100…240V AC or 24V AC (+10/-15%)
Supply Type 1-phase, 50/60 Hz
24V AC Power Requirement 130VA
100…240V AC Power Requirement 75VA
DC Control Voltage Input 24V DC (+10/-15%)
Inrush Current 5 A
Inrush Time 250 ms
Transient Watts 60 W
Transient Time 500 ms
Staedy State Watts 24 W
Recommended Supply 1606-XLP50E
Fan Power Input (AC only) separately wired
F5…F135 20VA
F201…F251 40VA
F317…F480 60VA
Conductor Range
0.75…2.5 mm
2
(18…14 AWG)
Torque 0.6 N•m (5 lb•in)
Maximum Number of Wires per Terminal 2
Control Voltage Input 110/120V AC or 230/240V AC, (+10/-15%)
Supply Type 1-phase, 50/60 Hz
Control Power Input 800VA (includes controller, bypass, and fans)
