Trusted Power System 4. Power Pack Specifications
Rockwell Automation Publication PD-T823X Issue 11 17
Parameter Min Type
Max Unit Note
Noise (20 MHz bandwidth) 300 mVp-p
Under any load conditions
Transmission Noise (C message) 45 dBmc
Output Rise Time 10 100 ms Rise from 10 % to 90 % of final
output level (resistive load)
Over-voltage Protection 29 32 Vdc Reset by cycling AC input, on/off,
or reinsertion
Output Current Limit (steady
state)
40A Adc
Transient Response
Voltage Range
-2 2 % 25
% step load transient with slew
rate 0.1 A/us within the range
from 25 % to 75 % of full load
Active Current Sharing Differential
±3.2 A Single wire current share at full
load
Efficiency
At full load, 120 Vac with
ORing diode
80 81 %
At full load, 264 Vac with
ORing diode
83.5 84 %
Reserve Output Current
Protection
ORing diode
Start-up Delay 1.3 2 S Measured from application of
valid AC voltage
Turn-on Delay 250 ms Measured from DC on/off
Table 5 Output Specification
