English-16
Advanced Group Parameters
No. Parameter Min/Max Display/Options Default
A051
A052
A053
A054
[Digital In1 Sel]
I/O Terminal 05
[Digital In2 Sel]
I/O Terminal 06
[Digital In3 Sel]
I/O Terminal 07
[Digital In4 Sel]
I/O Terminal 08
0/27 0 = “Not Used”
1 = “Acc & Dec 2”
2 = “Jog”
3 = “Aux Fault”
4 = “Preset Freq”
5 = “Local”
(1)
6 = “Comm Port”
7 = “Clear Fault”
8 = “RampStop,CF”
9 = “CoastStop,CF”
10 = “DCInjStop,CF”
11 = “Jog Forward”
12 = “Jog Reverse”
13 = “10V In Ctrl”
14 = “20mA In Ctrl”
15 = “PID Disable”
16 = “MOP Up”
17 = “MOP Down”
18 = “Timer Start”
19 = “Counter In”
20 = “Reset Timer”
21 = “Reset Countr”
22 = “Rset Tim&Cnt”
23 = “Logic In1”
24 = “Logic In2”
25 = “Current Lmt2”
26 = “Anlg Invert”
27 = “EM Brk Rlse”
4
4
5
11
(1)
Important: Speed source for IP66, NEMA/
UL Type 4X rated drives comes from A069
[Internal Freq].
A055 [Relay Out Sel] 0/24 0 = “Ready/Fault”
1 = “At Frequency”
2 = “MotorRunning”
3 = “Reverse”
4 = “Motor Overld”
5 = “Ramp Reg”
6 = “Above Freq”
7 = “Above Cur”
8 = “Above DCVolt”
9 = “Retries Exst”
10 = “Above Anlg V”
11 = “Logic In 1”
12 = “Logic In 2”
13 = “Logic 1 & 2”
14 = “Logic 1 or 2”
15 = “StpLogic Out”
16 = “Timer Out”
17 = “Counter Out”
18 = “Above PF Ang”
19 = “Anlg In Loss”
20 = “ParamControl”
21 = “NonRec Fault”
22 = “EM Brk Cntrl”
23 = “Above Fcmd”
24 = “MsgControl” (for
FRN 6.01 and later)
0
A056 [Relay Out Level] 0.0/9999 0.1 0.0
A058
A061
[Opto Out1 Sel]
[Opto Out2 Sel]
0/24 See A055 for Options. 2
1
A059
A062
[Opto Out1 Level]
[Opto Out2 Level]
0.0/9999 0.1 0.0
A064 [Opto Out Logic] 0/3 1 0
A064 Option Opto Out1 Logic Opto Out2 Logic
0 NO (Normally Open) NO (Normally Open)
1 NC (Normally Closed) NO (Normally Open)
2 NO (Normally Open) NC (Normally Closed)
3 NC (Normally Closed) NC (Normally Closed)
To Next Page
