WWW.Z21.EU
Model Railway Control Unit
40
CV Description Range Default
#49 Initialisation of outputs 1 to 4
Activation status for continuous operation and alternate ash outputs when switching on
the decoder power supply.
Bits 1.0 = output 1:
0.0 = off (decimal value 0)
0.1 = red (decimal value 1)
1.0 = green (decimal value 2)
1.1 = reserved (decimal value 3)
Bits 3.2 = output 2:
0.0 = off (decimal value 0)
0.1 = red (decimal value 4)
1.0 = green (decimal value 8)
1.1 = reserved (decimal value 12)
Bits 5.4 = output 3:
0.0 = off (decimal value 0)
0.1 = red (decimal value 16)
1.0 = green (decimal value 32)
1.1 = reserved (decimal value 48)
Bits 7.6 = output 4:
0.0 = off (decimal value 0)
0.1 = red (decimal value 64)
1.0 = green (decimal value 128)
1.1 = reserved (decimal value 192)
0 - 255 0
#50 Initialisation of outputs 5 to 8
Activation status for continuous operation and alternate ash outputs when switching on
the decoder power supply.
Bits 1.0 = output 5:
0.0 = off (decimal value 0)
0.1 = red (decimal value 1)
1.0 = green (decimal value 2)
1.1 = reserved (decimal value 3)
Bits 3.2 = output 6:
0.0 = off (decimal value 0)
0.1 = red (decimal value 4)
1.0 = green (decimal value 8)
1.1 = reserved (decimal value 12)
Bits 5.4 = output 7:
0.0 = off (decimal value 0)
0.1 = red (decimal value 16)
1.0 = green (decimal value 32)
1.1 = reserved (decimal value 48)
Bits 7.6 = output 8:
0.0 = off (decimal value 0)
0.1 = red (decimal value 64)
1.0 = green (decimal value 128)
1.1 = reserved (decimal value 192)
0 - 255 0
