roco Z21 switch DECODER User Manual

The Z21 is a FLEISCHMANN and ROCO innovation.
41
English
#51 Second decoder address, lower 6 bits (bits 0 - 5)
Together with CV #52, this generates the second decoder address for outputs 5 to 8.
If the second decoder address is set to 0, the rst decoder address plus 1 is then used for
outputs 5 to 8 automatically. This is also the recommended setting.
This CV can only be read. You can change the decoder addresses via the programming
button. See section Option 2 – Program address for outputs 5 to 8.
0 – 63
read only
0
#52
Second decoder address, upper 3 bits (bits 6 - 8)
Together with CV #51, this generates the second decoder address for outputs 5 to 6.
This CV can only be read. You can change the decoder addresses via the programming
button. See section Option 2 – Program address for outputs 5 to 8.
0 – 7
read only
0
#53 Time output 5 active, see CV #3 0 – 255 5
#54 Time output 6 active, see CV #3 0 – 255 5
#55 Time output 7 active, see CV #3 0 – 255 5
#56 Time output 8 active, see CV #3 0 – 255 5
#61 Dimming output 1
Reduction in brightness of lamps using PWM (pulse width modulation).
0 = dimming is deactivated, i.e. full brightness at the output.
1 to 100 = brightness in percent of the adjustable frame.
WARNING: This function is only suitable for light signals and lighting with a low connec-
tion load less than 1 A.
WARNING: LEDs also need a series resistor on the dimmed output.
0 - 100 0
#62 Dimming output 2, see CV #61 0 - 100 0
#63 Dimming output 3, see CV #61 0 - 100 0
#64 Dimming output 4, see CV #61 0 - 100 0
#65 Dimming output 5 see CV #61 1 - 100 0
#66 Dimming output 6, see CV #61 1 - 100 0
#67 Dimming output 7, see CV #61 1 - 100 0
#68 Dimming output 8, see CV #61 1 - 100 0
#71 Fade-In
Duration of the slow fade-in in 10ms increments for operating mode 2 (alternate ash) and
5 (continuous operation) with bulb simulation. See also CV#41-48 and CV#72.
The factory setting is 100ms.
1 - 100 10
#72 Fade-Out
Duration of the slow fade-out in 10ms increments for operating mode 2 (alternate ash)
and 5 (continuous operation) with bulb simulation. See also CV#41-48 and CV#71.
The factory setting is 200ms.
TIP: For the alternate ash, ensure that the total of the times of Fade-In plus Fade-Out
should be smaller than the desired cut-in time achieved by CV #3-#6 and CV #53-#56.
Otherwise, the total cut-in time would be extended accordingly, which would then result
in a lower alternate ashing frequency.
1 - 255 20
#250 Decoder Typ
36 = ROCO 10836 Z21 switch DECODER
read only 36
