ROCWARE RC310 - Appearance and Interfaces

RC310 1080P Video PTZ Camera User Manual
3
Communication
Interface
1 x RS232: 8pin Min DIN,
Max. Distance: 30m,
Protocol: VISCA/Pelco-D/
Pelco-P
Power Interface
JEITA type (DC 12V)
/USB Type-C (USB 5V)
General Specifications
Input Voltage DC 12V/USB 5V
Input Current
12V 1.0A (max.)/
5V 1.5A (max.)
Operating
Temperature
0°C~40°C
Storage
Temperature
-40°C~60°C
Power
Consumption
12W (max.)
Dimension (mm) 107.9 x 114.3 x 136.5
Net Weight About 0.5Kg
Product specifications are subject to change
without notice.
4.3 Appearance and Interfaces
No. Name
1 USB2.0 Interface
2 RS232 Interface
3 DC 12V Interface
4.4 Dimension
Unit: mm
Note
