Rohde & Schwarz R&S NRP Series User Manual

R&S NRP Power Sensors Tour
R&S
®
NRP Series
27Getting Started 1419.0170.02 ─ 12
Table 5-4: R&S NRPxxT(N) RF connector characteristics
Power sensor Male connector Matching female
connector
Tightening torque
R&S NRP18T
N N
1.36 Nm (12'' lbs)
R&S NRP18TN
R&S NRP33T
3.50 mm
3.50 mm/ 2.92 mm/
SMA
0.90 Nm (8'' lbs)
R&S NRP33TN
R&S NRP40T
2.92 mm
R&S NRP40TN
R&S NRP50T
2.4 mm
2.4 mm/ 1.85 mm
R&S NRP50TN
R&S NRP67T
1.85 mm
R&S NRP67TN
R&S NRP90T
1.35 mm 1.35 mm
R&S NRP90TN
R&S NRP110T 1.0 mm 1.0 mm 0.23 Nm (2'' lbs)
Table 5-5: R&S NRPxxTWG RF connector characteristics
Power sensor Male
connec-
tor
Matching
female
connector
Frequency range Tightening torque
R&S NRP75TWG
WR-15 WR-15
50 GHz to 75 GHz
0.58 Nm (5'' lbs)R&S NRP90TWG
WR-12 WR-12
60 GHz to 90 GHz
R&S NRP110TWG
WR-10 WR-10
75 GHz to 110 GHz
* Use the torque wrench of the R&S tool with the part number 1175.2014.02.
5.2 Trigger I/O Connector
The trigger I/O is a connector of SMB type.
It is used as an input for signals if the trigger source parameter is set to
EXTernal2. It is used as an output for trigger signals if the sensor is operated in
the trigger master mode.
Trigger I/O Connector
