Rohm PMIC BD96801 - Page 25

25/36
User’s Guide
BD96801-SPA7-EVK-301
© 2022 ROHM Co., Ltd.
65UG018E Rev.001
July 2022
Transistors
28
Q60, Q301, Q302, Q303, Q304, Q501,
Q502
NPN, digital transistor, SOT-
323FL
Rohm DTC013ZUBTL
Resistors
29
R1
Res Thick Film 0402 680K Ohm
1% 1/16W ±100ppm/°C Molded
SMD Paper T/R
Yageo AC0402FR-07680KL
30
R2
Res Thick Film 0402 100K Ohm
1% 1/16W ±100ppm/°C Molded
SMD Paper T/R
Yageo AC0402FR-13100KL
31
R4, R6, R9, R12, R202, R203, R204,
R205, R210, R313, R314, R315, R316,
R319, R325, R516, R520, R525, R530,
R547, R548, R549, R550
Res Thick Film 0402 0 Ohm
Jumper Molded SMD Paper T/R
Rohm SFR01MZPJ000
32
R7 Res Thick Film 0 Ohm, 1206 Vishay RCS12060000Z0EA
33
R8, R301
Res Thick Film 0402 10K Ohm
5% 1/16W ±200ppm/°C Molded
SMD
Rohm SFR01MZPJ103
34
R10
Thick Film Resistors - SMD 0402
Resistor 0.5% 100ppm
240KOhm
Panasonic ERJ2RKD2203X
35
R11
Thick Film Resistors - SMD Thick
Film Chip Res, 0402, 1/16W
0.5%, 0.5%, 30Kohm
KOA RK73H1ETTP3002D
36
R13, R106, R107, R201, R207, R208,
R209
Thick Film Resistors – SMD 0
ohms JUMPER, 0805
Vishay CRCW08050000Z0EAHP
37
R22, R23
Res Thick Film 0603 0 Ohm
Jumper Molded SMD Paper T/R
Rohm SFR03EZPJ000
38
R40, R309, R320, R321, R323, R326
Res Thick Film 0402 1K Ohm 5%
1/16W ±200ppm/°C Molded
SMD SMD Paper T/R
Rohm SFR01MZPJ102
39
R41, R60, R302, R317, R318
Res Thick Film 0402 220 Ohm
5% 1/16W ±200ppm/°C Molded
SMD SMD Paper T/R
Rohm SFR01MZPJ221
40
R42, R44, R50, R51, R52, R57, R100,
R102, R104, R105, R206, R401
Res Thick Film 0603 0 Ohm
Jumper Molded SMD Paper T/R
Vishay CRCW06030000Z0ECHP
41
R56, R130, R131
Res Thick Film 0603 10K Ohm
1% 1/10W ±100ppm/°C Molded
SMD SMD Paper T/R
Rohm SFR03EZPF1002
42
R135, R136, R137, R303, R324, R501,
R502
Res Thick Film 0402 330 Ohm
1% 1/16W ±100ppm/°C Molded
SMD Paper T/R
Rohm SFR01MZPF3300
43
R304, R305, R307, R308, R426
Res Thick Film 0402 1K Ohm
0.5% 1/16W ±50ppm/°C Molded
SMD Paper T/R
Panasonic ERJ-2RHD102X
44
R306
Res Thick Film 0402 100 Ohm
0.5% 200mW ±100ppm/°C
Molded SMD Paper T/R
Panasonic ERJ-PA2D1000X
45
R310
RES SMD 2.4K OHM 5% 1/16W
0402
Panasonic ERJ-S02F2401X
46
R311, R312, R322, R427
RES SMD 4.7K OHM 5% 1/16W
0402
ROHM SFR01MZPJ472
47
R402, R403, R404, R405, R406, R407,
R408, R409, R410, R411, R412, R413,
R414, R415, R416, R417, R418, R419,
R420, R421, R422, R423, R424, R425
Res Thick Film 0402 51 Ohm
0.5% 1/16W ±100ppm/°C
Molded SMD Paper T/R
Panasonic ERJ-H2RD51R0X
48
R428
Thick Film Resistors - SMD 0402
240ohms 0.5%AEC
-
Q200
Panasonic ERJ-2RHD2400X
49
R503, R504, R505, R506, R560, R561,
R562
Res Thick Film 0402 100K Ohm
5% 1/16W ±200ppm/°C Molded
SMD SMD Paper T/R
ROHM SFR01MZPF1003
50
R507, R508, R509, R510, R511, R512,
R513, R514, R515, R517, R518, R519,
R521, R522, R523, R524, R526, R527,
Res Thick Film 0402 100 Ohm
5% 1/16W ±200ppm/°C Molded
SMD SMD Paper T/R
ROHM MCR01MZPJ101
