R528, R529, R531, R532, R533, R534,
R535, R536, R537, R538, R539, R540,
R541, R542, R543, R544, R545, R546
Push buttons, switches
51
SW301, SW304 Push ALPS SKHMQKE010
52
SW302, SW303, SW501, SW502,
SW503, SW504
Slide ALPS SSSS820201
Test points
53
TP1, TP2, TP3, TP4, TP20, TP21,
TP40, TP41, TP100, TP101, TP102,
TP103, TP120, TP121, TP122, TP130,
TP131, TP135, TP136
TP KOA RCWCTE
54
TP132 TP black
Keystone
Electronics
5006
55
TP133 TP yellow
Keystone
Electronics
5008
56
TP134 TP white
Keystone
Electronics
5007
ICs
57
U1
Synchronous buck converter, 4.5
V to 36 V Input, 5 A Integrated
MOSFET, VMMP16LZ3030 pkg.
Rohm BD9F500QUZ
58
U2 BD96801 PMIC Rohm BD96801
59
U3
I2C bus EEPROM (2 wire), 1kbit,
SOP8
Rohm BR24T01F-WGE2
60
U4
Termination regulator DDR-
SDRAMs, SOP-J8
Rohm BD35395FJ-ME2
61
U201
Spartan-7 FPGA, CSGA324
wire-bond chip-scale (0.8mm
pitch)
Xilinx XC7S50-2CSGA324C
62
U302
Frequency oscillator, 200MHz,
3.2mm x 2.5mm, +/- 50ppm,
2.5V
SiTime
SIT9120AC-1B3-
25E200.000000D
63
U303
Serial NOR Flash Memory,
128MBit, 8
-
pin SOP2 (SO8W)
Micron
MT25QU128ABA1ESE-
0SIT
64
U402
DDR3L SDRAM, 32 Meg x 16 x
8 banks, 96-ball 8mm x 14mm
FBGA
Micron MT41K256M16TW-107P
Not mounted
65
C5, C20, C22, C43, C45, C101, C103,
C132, C133, R3, R5, R20, R21, R53,
R54, R55, R563, R564, R565
Not placed / not mounted
Table 7: bill of material (BOM)
