Rola Pick-Up-Rack - Tools Required

Product Code:
Product Name:
59742
A
2x
B
2x
C
2x
D
2x
E
2x
G
2x
H
2x
F
8x
I
4x
Pick-Up-Rack™
Please read all instructions carefully before assembly, installation and/or use of this product.
LEFT FRONT/
RIGHT REAR
RIGHT FRONT/
LEFT REAR
Cequent Performance Products, Inc.
Plymouth, MI 48170
Technical Service: (888) 521-0510
59742N Rev D 4-24-13
9/16” Socket
9/16” Wrench
1/8” Hex Key
Tools Required:
G
2x
H
2x
F
8x
I
4x
J
8x
K
8x L
16x
M
16x
N 1x
Page 2 of 6
Tape Measure
Utility knife
Printed in China
Parts included:
ITEM DESCRIPTION ITEM DESCRIPTION
A Vertical Support Left Hand I Crossbar Mounting Adapter
B Vertical Support Right Hand J 3/8-16 x 2.00 GR5 Carriage bolt (SS)
C Crossbar Assembly K 3/8-16 x 1.25 GR5 Carriage bolt (SS)
D Support Base Left Front / Right Rear L 3/8 Helical Lock Washer (SS)
E Support Base Right Front / Left Rear M 3/8-16 Hex Nut (SS)
F Clamp N
Hex Key Wrench 1/8"
G Cover & 1/4-20 Set Screw LH O Flat Washer 3/8 (SS)
H Cover & 1/4-20 Set Screw RH
O
8x
