Model
9
Operation
■
Try Producing Some Sound
1.
When you have finished making the connections, set the knobs and EQ as shown in the figure.
* For information on how to make the settings for the EQ, refer to step 3 on this page.
fig.00a.eps
* Setting the BODY knob and VOLUME knob to the center position.
2.
Adjust the BODY knob to get the desired sound.
fig.00b.eps
3.
Adjust the EQ levels until you achieve the tone you want.
Press the EQ/EDIT button (LEFT, RIGHT) to select the frequency to be adjusted, then press the EQ/EDIT
button (UP, DOWN) to adjust the level of the selected frequency.
* Pressing the EQ/EDIT button (UP, LEFT, DOWN, RIGHT) causes the segment you're adjusting to flash. If the EQ/
EDIT button is not operated again within five seconds, the EQ settings mode ends automatically.
fig.01-e.eps
* Starting from the left, the indicator segments correspond to 200 Hz, 400 Hz, 800 Hz, 1.6 kHz, 3.2 kHz, 6.4 kHz, and 12.8
kHz. Each EQ frequency can be cut or boost by up to 6 dB.
* Holding down the EQ/EDIT button (CENTER) for at least one second switches off the EQ.
Holding down the button again for at least one second switches on the EQ.
* The results of EQ adjustment are automatically saved for respective variations.
4.
Adjust the VOLUME knob so that the output sound does not distort at maximum volume
when the instrument is played vigorously.
Adjuststhelevel
Selectsthefrequency
EQ is off
400Hz
-6dB
+6dB
200Hz 800Hz
1.6kHz
3.2kHz 12.8kHz
6.4kHz
EQ is on
PREAMP
