Roland EXR-7 Service Notes

Apr.2004
12
# J5339104 ZENER DIODE EDZ7.5B 7,5V CHIP 1
RESISTOR
J3709119 RESISTOR 4.7K OHM 1/8W 5% 6
J3919104 RESISTOR ARRAY EXB-A10E-103-J 12
J3919107 RESISTOR ARRAY EXB-V8V-101-JV 4
J3919108 RESISTOR ARRAY EXB-V8V-103-JV 5
J3919109 RESISTOR ARRAY EXB-V8V-470-JV 10
J3919116 RESISTOR ARRAY EXB-V8V-220-JV 1
J3919115 RESISTOR ARRAY EXB-V8V-223-JV 3
J3809127 UNINFL. RES. 22 OHM 1/4W 1
J3809158 ININF. RESISTOR 3.3 0.6W 5% 1
J3809150 UNINFL.RES. 33 OHM 1/4W 5% 8
J3809156 UNINFL. RES. 47 OHM 0.6W 5% 4
J3809139 OXIDE RESISTOR 2.2 OHM 3W 2
01783623 RESIST. 2010 10 OHM1/2W 5% 4
POTENTIOMETER
00459901 ROT. POT. 10KB 14K 1230 1
13299206 TRIMMER POT. EVND 8AA03B24 1
CAPACITOR
J3549105 POLY.COND. 10NF 5% P.5 4
J3549106 POLY.COND. 100NF 5% P.5 9
# J3549125 POLY.COND. 68NF 5% P.5 2
J3629164 POLY. COND. 680N 5% P.5 3
J3629165 CONDENSER 820N 5% P.5 POLIE 1
J5369110 CONDENSER 0603 150P NP0 5% 1
J3629144 ELCTRL.COND. 470UF 16V AX 1
J3469156 ELECTR. COND. 33U 35V P.5 8
J3629122 ELECTRL.COND.-V 1000UF 25V 4
J3629103 ELECTRL.COND. 100U 25V P5 12
J3629104 ELECTRL.COND. 10U 50V P5 7
J3629105 ELECTRL.COND. 47U 50V P5 1
J3629107 ELECTRL.COND. 1UF 100V P5 3
J5369103 ELECTR.CAPACITOR RV2 100U 16V (SMD) 3
J5369104 ELECTR. COND. RV2 10U 16V (SMD) 23
J5369105 ELECTR.CAPACITOR RV3 33U 16V (SMD) 15
J5369106 ELECTR. COND. RV2 1U 50V (SMD) 3
J3629149 ELECTR.COND. 100U 16V H.7 1
J3629143 ELECTR. COND. 10U 16V H.7 2
J3629137 ELECTR. COND. 33U 16V H.7 3
J3629142 ELECTR. COND. 1U 63V H.7 1
13649103J0 UNPOL.COND. 10U 50 P5 4
INDUCTOR, COIL, FILTER
<<EMI>> 12449382RI NOISE SUP. PLT1-R53C 1
<<EMI>> 12449380 NOISE SUP. EXC-ELDR25V 2
<<EMI>> 00452034 CHIP NOISE SUP. BK2125HM102 38
<<EMI>> 12449355 NOISE SUP. FBR07H850TB00 3
<<EMI>> 01340834 FERRITE BEAD EXCML 20A390 4
<<EMI>> J2399109 NOISE SUP. ELKE471FA CHIP 1
CRYSTAL, RESONATOR
00894034 X-TAL 16 MHZ MA-406 1
00901912 X-TAL 24.576 MHZ MA-406 1
01340745 XTAL MA-406 12MHZ 1
01126267 X-TAL 7.056 MHZ MA-406 1
J2389104 RESONATOR CSTLS4M00G53-BO (4MHZ) 1
CONNECTOR
13419677RI 16P FEM. CONNECTOR AMP 1.27 3
13369689RI 20P FEM. CONNECTOR AMP 1.27 3
J3429122 14P FEM. CONNECTOR AMP 1.27 4
J3429129 FEMALE CONNECTOR 18P AMP1.27 1
J3429130 8P FEMALE CONNECTOR PHR-8 P.2 JST 2
13369688RI 4P MALE CONN. P 2.5 M 2
J3439120 4P MALE CONN. P.2 M 1
J3439121 6P MALE CONN. P.2 M 1
J3439143 34P MALE CONN. P. 1.27 M 1
J3439123 6P MALE CONN. P. 2 M 90 2
J3439148 7P MALE CONNECTOR P.2 M 4
J3439184 4P MALE CONNECTOR 90 P.2.5M 5046-04 1
J3439189 8P MALE CONNECTOR B8B-PH-K-S P.2 JST 2
WIRING, CABLE
# K3468283 4P CABLE ASSY (86) -2C D/R 1
K3468264 14P FLAT CABLE (12) -2C D/R 1
K3468207 34P FLAT CABLE (60) + FERRITE 1
J3469159 AWG18 CBL (12) GREEN + FASTON (2) 2
# 7775713000 3P CABLE ASSY 2V/1R (52) -4P 2C D/D 1
# 7775714000 2P COAXIAL CABLE ASSY (36) -2C P.2 D/R 1
7712023000 7P CABLE ASSY (72) -2C P.2 D/R 1
