Apr.2004
10
PARTS LIST
When ordering any parts listed in the parts list,please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
CONSIDERATION ON PARTS ORDERING
NOTE:
# The parts marked " # '' are new (Initial Parts).
A The parts marked " A '' are new (Initial Parts).for RES but already used by RJA
The parts marked have Safety - Related characteristics.
Use only listed parts for replacement.
<< EMI >> Component for EMC.
Note :: Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
CASING Q.ty
K2248187 RIGHT/LEFT LOUDSPEAKER GRILL EXR-5 2
K2198114 PLASTIC MUSIC REST EXR-5 1
# 7775709000 VARN+SILK. KEYBOARD BLIND EXR-7 1
# 7775710000 BLACK VARN. + CUNDUCTIVE BOTTOM CBNT 1
# 7775711000 VARN.+SILK TOP CBNT EXR-7 1
KNOB BUTTON
K2478265 BLACK KNOB 1420 E/D. 24 H.9 1
K2478304 BUTTON 12X8 WHITE 3
K2478306 BUTTON 16X10 WHITE 31
K2478313 BUTTON 20X10 WHITE 8
K2478314 BUTTON 20X10 DARK GREY 1
K2478373 BUTTON 16X10 DARK GREY 5
3249559701 SWITCH CAP 1
K2478376 DARK GREY BUTTON 12/08 (9) EXR-5 1
K2478377 DARK GREY BUTTON 12X8 (0) EXR-5 1
K2478378 DARK GREY BUTTON 12X8 (-) EXR-5 1
K2478379 DARK GREY BUTTON 12X8 (+) EXR-5 1
K2478380 WHITE BUTTON 20X10 (USER PROGRAM) EXR-5 1
K2478381 WHITE BUTTON 20X10 (DISK) EXR-5 1
K2478382 WHITE BUTTON 20X10 (FUNCTION) EXR-5 1
K2478383 WHITE BUTTON 20X10 (TONE) EXR-5 1
K2478384 WHITE BUTTON 20X10 (STYLE) EXR-5 1
K2478385 WHITE BUTTON 20X10 (SONG) EXR-5 1
K2478386 WHITE BUTTON 20X10 (MUSIC ASSISTANT) 1
K2478387 DARK GREY BUTTON (DOUBLE ARROW) EXR-5 4
K2478388 DARK GREY BUTTON 12X8 (1) EXR-5 1
K2478389 DARK GREY BUTTON 12X8 (2) EXR-5 1
K2478390 DARK GREY BUTTON 12X8 (3) EXR-5 1
K2478391 DARK BUTTON 12X8 (4) EXR-5 1
K2478392 DARK GREY BUTTON 12X8 (5) EXR-5 1
K2478393 DARK GREY BUTTON 12X8 (6) EXR-5 1
K2478394 DARK GREY BUTTON 12X8 (7) EXR-5 1
K2478395 DARK GREY BUTTON 12X8 (8) EXR-5 1
# K2478410 WHITE BUTTON 20X10 (EXIT) 1
SWITCH
01676512 PUSH SWITCH SDKLA1-B 1
J3169105 SWITCH TP-1101A / EVQ-PAE 05 R 76
JACK, SOCKET
13449252 JACK SOCKET YKB 21-5006 2
13449283 JACK SOCKET HLJ7101-01-3010 3
13429825 5P DIN SOCKET YKF51-5054 (2PCS) 1
01459945 USB SOCKET YKF45-0002 1
DISPLAY UNIT
# 7775712000 LCD ASSY+WIRING EXR-7 1
DISK DRIVE UNIT
J240910601 FLOPPY D.DRIVER JU-257A167P 1
BENDER UNIT
# Note :: K3278112 PITCH BENDER SW + CABLE (36)+1C. 1
SPEAKER
K2418125 LOUDSPEAKER MM.130 4OHM RIF.2313 2
To Next Page
