201
Settings Common to All Modes (System Function)
[F1 (GENERL)]
[F2 (TRIGGER)]
[F3 (ASSIGN)]
System Menu [F5 (D BEAM)]
Parameter
Value Explanation
SENSIBILITY
D Beam Sens
0–127 This sets the D Beam controller’s sensitivity.
The higher the value set, the more readily the D Beam Controller goes to into erect.
PART
D Beam Part Select
KBD, PAD Part controlled by the D Beam controller
Parameter
Value Explanation
Pad Number
1–9 Pad number affected by the D Beam
Pad Velocity 1–127 Strength of the pad sound played by the D Beam controller
Pad Control Mode MOMENTARY,
LATCH
Specifies how the D Beam will behave when it is obstructed.
MOMENTARY:
The parameter will be on only while the D Beam is obstructed, and will turn off
when you stop obstructing it.
LATCH:
The parameter will alternately be switched on/off each time you obstruct the D Beam.
Parameter Value Explanation
Type CC01–31, 33–95,
BEND UP,
BEND DOWN,
START/STOP,
TAP TEMPO,
ARP GRID,
ARP DURATION,
ARP MOTIF,
ARP OCTAVE UP,
ARP OCTAVE DOWN
Function controlled by the D Beam controller
CC01–31, 33–95:
Controller numbers 1–31, 33–95
BEND UP:
Controls the pitch as specified by the “Pitch Bend Range Up” setting (p. 41).
BEND DOWN:
Controls the pitch as specified by the “Pitch Bend Range Down” setting (p. 41).
START/STOP:
Starts/Stops the sequencer.
TAP TEMPO:
Tap tempo (a tempo specified by the interval at which you move your hand over the
D Beam controller).
ARP GRID:
Arpeggio Grid
ARP DURATION:
Duration of each arpeggiated note
ARP MOTIF:
Arpeggio Motif
ARP OCTAVE UP:
The range in which the arpeggio is sounded will rise in steps of an octave (max-
imum 3 octaves).
ARP OCTAVE DOWN:
The range in which the arpeggio is sounded will lower in steps of an octave
(maximum 3 octaves).
Range Min 0–127 Lower limit of the range of the D Beam controller
Range Max 0–127 Upper limit of the range of the D Beam controller.
By setting Range Max below Range Min you can invert the range of change.
Fantom-Xa_e.book 201 ページ ２００４年１０月２２日 金曜日 午後２時３分
