8
Before You Play
Making Connections
1.
Before you begin making connections, confirm the following.
Is the volume level of the FP-5 turned all the way down?
Is the power to the FP-5 turned off?
2.
Connect the supplied AC cable to the supplied AC adaptor.
fig.00-01
3.
Connect the supplied AC adaptor to the FP-5, and then plug
its other end into a power outlet.
To prevent the inadvertent disruption of power to your unit (should the
plug be pulled out accidentally), and to avoid applying undue stress to the
AC adaptor jack, anchor the power cord using the cord hook, as shown in
the illustration.
fig.00-02
Installing the Music Stand
fig.00-03
1.
Using the supplied screws, attach the music stand to the
back of the FP-5 as illustrated.
Be sure to use the supplied screws for attaching the music stand.
Turn the screws clockwise until they’re held in place–but don’t tighten them
yet.
2.
Put the music stand between the screws and the FP-5’s body.
3.
While supporting the music stand with one hand, secure it in
place by turning the screws.
* When attaching the music stand, support it firmly with one hand to make sure that
you don’t drop it. Be careful, so you don’t get your fingers pinched.
4.
To remove the music stand, support it with one hand while
loosening the screws.
* After removing the music stand, don’t forget to retighten the screws.
Power outlet
AC adaptor
AC cable
NOTE
Do not apply excessive
force to the installed music
stand.
FP-5_e.book 8 ページ ２００５年１月２６日 水曜日 午前１０時２２分
