MIDI Implementation
Model: GR-20
Date: Dec. 18 2003
Version: 1.00
1. Recognized Receive Data
■
Channel Voice Message
●
Note Off
STATUS SECOND THIRD
8nH kkH vvH
9nH kkH 00H
n=MIDI Channel Number: 0H - FH (ch.1 - ch.16)
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity: 00H - 7FH (0 - 127)
* Velocity is ignored.
●
Note On
STATUS SECOND THIRD
9nH kkH vvH
n=MIDI Channel Number: 0H - FH (ch.1 - ch.16)
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity: 01H - 7FH (1 - 127)
* vv=00H is received as Note-off
●
Control Change
❍
Bank Select
STATUS SECOND THIRD
BnH 00H mmH
n=MIDI Channel Number: 0H - BH (ch.1 - ch.12)
mm=Bank Number: 00H - 0AH
* The LSB of Bank Select is ignored.
* Can be received only through the Basic channel.
❍
Foot Type
STATUS SECOND THIRD
BnH 04H vvH
n=MIDI Channel Number: 0H - BH (ch.1 - ch.12)
vv=Control Value: 00H - 7FH (0 - 127)
* Can be received only through the Basic channel.
* Received when EXP PEDAL TYPE = “FL”, “EF”.
❍
Volume
STATUS SECOND THIRD
BnH 07H vvH
n=MIDI Channel Number: 0H - BH (ch.1 - ch.12)
vv=Volume: 00H - 7FH (0 - 127)
* Can be received only through the Basic channel.
❍
General Purpose #3
STATUS SECOND THIRD
BnH 12H vvH
n=MIDI Channel Number: 0H - FH (ch.1 - ch.16)
vv=Control Value: 00H - 7FH (0 - 127)
* When E FLW is on, and recognized as the string envelope follow values.
❍
Hold1
STATUS
SECOND THIRD
BnH 40H vvH
n=MIDI Channel Number: 0H - BH (ch.1 - ch.12)
vv=Control Value: 00H - 7FH (0 - 127)
00H-3FH=OFF, 40H-7FH=ON
* Can be received only through the Basic channel.
●
Program Change
STATUS
SECOND
CnH ppH
n=MIDI Channel Number: 0H - BH (ch.1 - ch.12)
pp=Program Number: 00H - 7FH (0 - 127) 0=prg.1 127=prg.128
* Can be received only through the Basic channel.
* The recognized Program Change Number corresponds to each patch as follows.
BANK MSB PROGRAM NUMBER PATCH
0 0 USER1
0 1 USER2
0 2 USER3
0 3 USER4
0: :
0 97 USER98
0 98 USER99
1 0 PIANO1
1 1 PIANO2
1 3 PIANO3
::
2 0 ORGAN/KB1
2 1 ORGAN/KB2
2 3 ORGAN/KB3
::
3 0 BASS/GTR1
3 1 BASS/GTR2
3 3 BASS/GTR3
::
4 0 BRASS1
4 1 BRASS2
4 3 BRASS3
::
5 0 WIND1
5 1 WIND2
5 3 WIND3
::
6 0 STRING/ORCH1
6 1 STRING/ORCH2
6 3 STRING/ORCH3
::
7 0 SYNTH/LEAD1
7 1 SYNTH/LEAD2
7 3 SYNTH/LEAD3
::
8 0 VOICE/PAD1
8 1 VOICE/PAD2
8 3 VOICE/PAD3
::
9 0 ETHNIC1
9 1 ETHNIC2
9 3 ETHNIC3
::
10 0 RYTHM/PERC1
10 1 RYTHM/PERC2
10 3 RYTHM/PERC3
::
