MIDI Implementation
CTRL2 Drive 0 - 127
CTRL3 AMP Type 0 - 3 SMALL,BUILTIN,2STACK,3STACK
CTRL4 Output Pan 0 - 127 L64 - 63R
CTRL5 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 4: DISTORTION
CTRL1 Input Level 0 - 127
CTRL2 Drive 0 - 127
CTRL3 AMP Type 0 - 3 SMALL,BUILTIN,2STACK,3STACK
CTRL4 Output Pan 0 - 127 L64 - 63R
CTRL5 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 5: Lo-Fi
CTRL1 BitDown 0 - 7
CTRL2 S-Rate Down 0 - 3 32,16,8,4
CTRL3 Post Gain 0 - 3 0,+6,+12,+18
CTRL4 Low Gain 0 - 30 -15 - +15
CTRL5 High Gain 0 - 30 -15 - +15
CTRL6 Output 0 - 1 MONO,STEREO
CTRL7 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 6: NOISE
CTRL1 Noise Type 0 - 17 1 - 18
CTRL2 Noise Level 0 - 127
CTRL3 N Filter 0 - 17 *1,BYPASS
CTRL4 Lo-Fi Level 0 - 127
CTRL5 Output Pan 0 - 127 L64 - 63R
CTRL6 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 7: RADIO TUNG
CTRL1 Radio Detune 0 - 127
CTRL2 Noise Level 0 - 127
CTRL3 Low Gain 0 - 30 -15 - +15
CTRL4 High Gain 0 - 30 -15 - +15
CTRL5 Output 0 - 1 MONO,STEREO
CTRL6 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 8: PHONOGRAPH
CTRL1 Disc Type 0 - 2 LP,EP,SP
CTRL2 D Noise Level 0 - 127
CTRL3 Depth 0 - 20 0 - +20
CTRL4 Output Pan 0 - 127 L64 - 63R
CTRL5 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 9: COMPRESSOR
CTRL1 Attack 0 - 127
CTRL2 Sustain 0 - 127
CTRL3 Post Gain 0 - 3 0,+6,+12,+18
CTRL4 Low Gain 0 - 30 -15 - +15
CTRL5 High Gain 0 - 30 -15 - +15
CTRL6 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 10: LIMITER
CTRL1 Threshold 0 - 127
CTRL2 Ratio 0 - 3 1.5:1,2.0:1,4.0:1,100:1
CTRL3 Release 0 - 127
CTRL4 Post Gain 0 - 3 0,+6,+12,+18
CTRL5 Output Pan 0 - 127 L64 - 63R
CTRL6 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 11: SLICER
CTRL1 Timing Pattern 0 - 33
CTRL2 Rate 0 - 2 1/4,1/2,1/1
CTRL3 Accent Pattern 0 - 15
CTRL4 Accent Level 0 - 127
CTRL5 Attack 0 - 9 1 - 10
CTRL6 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 12: TREMOLO
CTRL1 LFO Type 0 - 5 TRI,TRP,SIN,SAW1,SAW2,SQR
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Low Gain 0 - 30 -15 - +15
CTRL5 High Gain 0 - 30 -15 - +15
CTRL6 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 13: PHASER
CTRL1 Manual 0 - 125 100 - 8000
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Resonance 0 - 127
CTRL5 Mix 0 - 127
CTRL6 Output Pan 0 - 127 L64 - 63R
CTRL7 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 14: CHORUS
CTRL1 Pre Delay 0 - 125 0.0 - 100
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Phase 0 - 90 0 - 180
CTRL5 Filter Type 0 - 2 OFF,LPF,HPF
CTRL6 Cutoff 0 - 16 *1
CTRL7 Balance 0 - 100 D100:0W - D0:100W
CTRL8 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 15: SPACE-D
CTRL1 Pre Delay 0 - 125 0.0 - 100
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Phase 0 - 90 0 - 180
CTRL5 Low Gain 0 - 30 -15 - +15
CTRL6 High Gain 0 - 30 -15 - +15
CTRL7 Balance 0 - 100 D100:0W - D0:100W
CTRL8 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 16: TETRA CHORUS
CTRL1 Pre Delay 0 - 125 0.0 - 100
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Pre Dly Devi 0 - 20
CTRL5 Depth Devi 0 - 40 -20 - +20
CTRL6 Pan Devi 0 - 20
CTRL7 Balance 0 - 100 D100:0W - D0:100W
CTRL8 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 17: FLANGER
CTRL1 Pre Delay 0 - 125 0.0 - 100
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Feedback 0 - 98 0 - +98
CTRL5 Phase 0 - 90 0 - 180
CTRL6 Filter Type 0 - 2 OFF,LPF,HPF
CTRL7 Cutoff 0 - 16 *1
CTRL8 Balance 0 - 100 D100:0W - D0:100W
CTRL9 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 18: ST FLANGER
CTRL1 Pre Delay 0 - 125 0.0 - 100
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Depth 0 - 127
CTRL4 Feedback 0 - 98 0 - +98
CTRL5 Phase 0 - 90 0 - 180
CTRL6 Step Rate 0 - 125 0.05 - 10.00,*3
CTRL7 Balance 0 - 100 D100:0W - D0:100W
CTRL8 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 19: SHORT DELAY
CTRL1 Time L 0 - 103 0.1 - 190
CTRL2 Time R 0 - 103 0.1 - 190
CTRL3 HF Damp 0 - 17 *1,BYPASS
CTRL4 Feedback 0 - 98 0 - +98
CTRL5 Auto Pan 0 - 18 OFF,*2
CTRL6 Low Gain 0 - 30 -15 - +15
CTRL7 High Gain 0 - 30 -15 - +15
CTRL8 Balance 0 - 100 D100:0W - D0:100W
CTRL9 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 20: AUTO PAN
CTRL1 LFO type 0 - 5 TRI,TRP,SIN,SAW1,SAW2,SQR
CTRL2 Rate 0 - 117 0.1 - 10.00,*2
CTRL3 Bass Sense 0 - 2 OFF,MODE1,MODE2
CTRL4 Depth 0 - 127
CTRL5 Low Gain 0 - 30 -15 - +15
CTRL6 High Gain 0 - 30 -15 - +15
CTRL7 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 21: FB PITCH SHIFTER
CTRL1 Coarse 0 - 36 -24 - +12
CTRL2 Fine 0 - 100 -100 - +100
CTRL3 Output Pan 0 - 127
CTRL4 Pre Delay 0 - 125 0.0 - 100
CTRL5 Mode 0 - 4 1 - 5
CTRL6 Feedback 0 - 98 0 - +98
CTRL7 Low Gain 0 - 30 -15 - +15
CTRL8 High Gain 0 - 30 -15 - +15
CTRL9 Balance 0 - 100 D100:0W - D0:100W
CTRL10 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 22: REVERB
CTRL1 Rev Type 0 - 5 ROOM1,ROOM2,STAGE1,STAGE2,
HALL1,HALL2
CTRL2 Time 0 - 127
CTRL3 HF Damp 0 - 17 *1,BYPASS
CTRL4 Balance 0 - 100 D100:0W - D0:100W
CTRL5 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 23: GATE REVERB
CTRL1 Gate Type 0 - 3 NORMAL,REVERSE,SWEEP1,SWEEP2
CTRL2 Gate Time 0 - 65 5 - 330
CTRL3 Balance 0 - 100 D100:0W - D0:100W
CTRL4 Output Level 0 - 127
--------------------------------------------------------------------------------
Type 24: ISOLATOR
CTRL1 Low gain 0 - 127
CTRL2 Mid gain 0 - 127
CTRL3 High gain 0 - 127
CTRL4 Output Pan 0 - 127 L64 - 63R
CTRL5 Output Level 0 - 127
================================================================================
* 1: 200, 250, 315, 400, 500, 630, 800, 1000, 1250,
* 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000
* 2: 1/16, 1/12, 3/32, 1/8, 1/6, 3/16, 1/4, 1/3, 3/8,
* 1/2, 2/3, 3/4, 1/1, 2MES, 3MES, 4MES, 8MES, 16MES
* 3: 1/16, 1/12, 3/32, 1/8, 1/6, 3/16, 1/4, 1/3, 3/8, 1/2
■1-2-2.Part Info Part
+——————————————————————————————————————————————————————————————————————————————+
| Offset | | |
| Address | Size | Description Data (Value) |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 000a | Receive Switch 0 — 1 (OFF,ON) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 01 | 0aaa aaaa | Reserved —— |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 02 | 0000 00aa | Patch Group Type 0 — 3 *2 |
| 00 03 | 0aaa aaaa | Patch Group ID 1 — 9 *2 |
|# 00 04 | 0000 aaaa | Patch Number 0 — 127 *2 |
| | 0000 bbbb | (001 — 128)|
| 00 06 | 0aaa aaaa | Part Level 0 — 127 |
| 00 07 | 0aaa aaaa | Part Pan 0 — 127 (L64 — 63R)|
| 00 08 | 0aaa aaaa | Part Key Shift 0 — 96 (—48 — +48)|
| 00 09 | 0aaa aaaa | Part Fine Tune 0 — 100 (—50 — +50)|
| 00 0A | 0000 0aaa | MFX Switch 0 — 4 *1 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0B | 0aaa aaaa | Reserved —— |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 0aaa aaaa | Delay Send Level 0 — 127 |
| 00 0D | 0aaa aaaa | Reverb Send Level 0 — 127 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0E—00 19 | 0aaa aaaa | Reserved —— |
|—————————————+————————————————————————————————————————————————————————————————|
| Total size | 00 00 00 1A |
+——————————————————————————————————————————————————————————————————————————————+
* 1: OFF, ON, Reserved, Reserved, RHY
* 2: Refer to the chart below
[Patch]
+---------------++----------------+--------------+------------++-----------+-----------+
| || | | ||Bank Select| |
|Patch ||Patch Group Type|Patch Group ID|Patch Number|| MSB | LSB |Program No.|
|---------------++----------------+--------------+------------++-----+-----+-----------+
|P-A001 - P-A128|| 0| 3| 0 - 127|| 81| 0| 1 - 128|
|P-B001 - P-B128|| 0| 4| 0 - 127|| 81| 1| 1 - 128|
|P-C001 - P-C128|| 0| 5| 0 - 127|| 81| 2| 1 - 128|
|P-D001 - P-D128|| 0| 6| 0 - 127|| 81| 3| 1 - 128|
|P-E001 - P-E088|| 0| 7| 0 - 87|| 84| 0| 1 - 88|
|P-U001 - P-U128|| 3| 1| 0 - 127|| 85| 0| 1 - 128|
|P-U129 - P-U256|| 3| 2| 0 - 127|| 85| 1| 1 - 128|
+---------------++----------------+--------------+------------++-----+-----+-----------+
[Rhythm set]
+-------------++----------------+--------------+------------++-----------+-----------+
| || | | ||Bank Select| |
|Rhythm set ||Patch Group Type|Patch Group ID|Patch Number|| MSB | LSB |Program No.|
|-------------++----------------+--------------+------------++-----+-----+-----------+
|R-A01 - R-A26|| 0| 3| 0 - 25|| 81| 0| 1 - 26|
|R-B01 - R-B04|| 0| 4| 0 - 3|| 84| 0| 1 - 4|
|R-U01 - R-U20|| 3| 1| 0 - 19|| 85| 0| 1 - 20|
+-------------++----------------+--------------+------------++-----+-----+-----------+
