Roland GX-24 Manual

1-1 COVERS
PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts-
Parts No. Parts Name
Parts No. Parts Name
1
22095160 APRON,B GX-24
S1
31019159 SCREW,BINDING M4*6 NI
2
22095159 APRON,F GX-24
S2
31289102AS CUPSCREW SET,M3*6 NI 50 PCS.
3 W022805612 ASSY,PANEL BOARD GX-24 S3
31019401 SCREW,BINDING M4*6 NI+EXT.TW
4 21835115 BOARD,LCD S2K16 TW S4
31019703 SCREW SET,BINDING P-TIGHT 3*8 BC 100 PCS.
5 23415321 CABLE-ASSY,LCD GX-24 S5
31299102AS RIVET SET,NYLON P2655B 20PCS.
6 23475244 CABLE-CARD,17P1.0 150L BB GX-24 S6
1000000020 CLAMP,FLAT CABLE FCC-25A
7
22335156 CAP,PANEL F GX-24
8
22045390 COVER,FRONT GX-24
9 22045381 COVER,PANEL GX-24
10
22045383 COVER,SIDE L GX-24
11
22045382 COVER,SIDE R GX-24
12
22045391 COVER,TOP GX-24
13 22495102 KEY TOP,CLEAR GX-24
14 22495101 KEY TOP,WHITE GX-24
15
22535287 LABEL,CAUTION CARRIAGE #LA266
16
22215115 PANEL,F TOP GX-24
17
22215114 PANEL,F UNDER GX-24
18 21475192 SHEET,LCD GX-24
19 22715492 STAY,PANEL GX-24
20
22785117 SUPPORT,PANEL F GX-24
21
21445115 TRAY,GX-24
1-2

Roland GX-24 Specifications

General

Cutting Speed	Up to 20 inches/sec (500 mm/sec)
Distance Accuracy	±0.004 inches (±0.1 mm) or less
Repeatability	±0.1 mm (0.0004 in.) or less
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5 to 40°C (41 to 104°F)
Operating Humidity	35 to 80% RH (non-condensing)
Software Resolution	0.025 mm/step (0.001 in./step)
